Indoor Full Color LED Video Display (P7)

Name: Indoor Full Color LED Video Display (P7)
Brand: china-manufacturer-directory.com
SKU: 699591805
Availability: InStock
Rating: 5 (91 reviews)

Supplier:	Shenzhen CreateLED Electronics Co., Ltd.
Price:	US $ 2500-3500/Square Meter
Min Order:	1/Square Meter
Quantity::
Trade Terms:	EXW

Product Specifications

Prod Model:	AirLED-7
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
LED Type:	3-in-1 SMD
Brightness:	1, 200nits-1, 500nits
Contrast Ratio:	2000: 1
Tube Chip Color:	Full Color
Display Function:	Video Display
Scanning Mode:	1/8 Scan
Application:	Events, Concert, Touring
Pixel Configuration:	1R,1G,1B
Certification:	EMC
System Operating Platform:	WIN XP
Pixel Pitch:	7.8mm
IP Rating:	for Indoor Use Only
Pixel Density:	16, 384dots/Sqm

Product Description

CreateLED AirLED-7 indoor LED display is the classical, enduring product, the ideal product to serving the highly demanding rental & staging market by offering the deepest black levels available on the market, AirLED-7 Indoor Full Color LED Video Display Board is also a very attractive product for fixed installations with minimal maintenance, limited thickness and low power consumption. Indoor LED Display Full Color Video Board with Certification CE&RoHS& EMC.

AirLED-7 Indoor LED Display Full Color Video Board have robust precision extruded aluminum section and contrast ration comprised for both rental and permanent installations.

Key benefits:
1. Ultra-light weight and slim design, 7kg/panel, 28kg/sqm,
2.500mmx50mm Standard panel size, making flexible assembling and dismantling
3.40000: 1 Higher contrast ratio with true black body SMD available
4. Ideal for Car Shows, TV Shows, Theater and Arts, Fanless design and front maintenance
5. Quick lock system allowing handling fast
6. High refresh rate available for capture for DV&VCR

AirLED-7
Pixel Pitch	7.8mm
LED Type	3-in-1 SMD
Brightness	1, 200nits-1, 500nits
Viewing Angle	H: 160 degree
Viewing Angle	V: 100 degree
Contrast Ratio	2000: 1
Pixel Density	16, 384/sqm
	1, 524/sqf
	4, 096/panel; 6, 144/panel
Module Size	250mm x 250mm
Module Resolution	32 x 32
Panel Size(WxHxD)	500mmx500mmx65mm
Panel Resolution	64 x 64
Weight	7kg/panel
Power Consumption	110W/Panel Max
Power Consumption	44W/Panel Ave
Processing	16 bit/color
Refresh Rate	1, 200-4, 000Hz
Drive Method	1/8 Scan Method
Environment	Indoor
Max Stacking	20 panels
Max Hanging	20 panels
Servicing	Front & Back
Panel Material	Precision Extruded Aluminum Section
Source Compatibility(with Processor)	VGA(RGBHV), DVI, HDMI, SDI(HDSDI)

Shenzhen CreateLED Electronics Co, . Ltd. Is one of the most professional LED Screen manufacturer to provide full solutions for fixed billboard market and rental market.

Especially since year of 2010 we explored and issued the innovative newly AirLED series for rental customers, standard solution for different applications, standard solution for ourselves mass production.

About outdoor fixed installation billboard, we are promoting the full viewing angle, complete water proof and lower power drive method outdoor cabinets, which is leading the trend of this billboard market.
