Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Fiber Optic Cable |
| Conductor Material: |
Plastic |
| Certification: |
UL |
| Type: |
Fiber Optical Cable |
| Wire Core Material: |
Fiber Optcial |
| Brand: |
Sinohone |
Product Description
Description
The cable consists of individually colour coded 900µmsecondary coated fibres, embedded in an E-glass yarn, and oversheathed with a single Low Smoke Zero Halogen (LSZH) outer jacket. The jacket is flame retardant, UV stabilised and extremely resistant to the ingress of moisture. Their small diameter, lightweight and excellent environmental performance makes these cables ideal for installation in a broad range of network applications including LAN backbones, networks with mixed indoor and outdoor cabling, outdoor in flooded ducts and any premises distribution system.
Specification
Jacket Material Black LSZH
Crush Resistance 2000 N/10cm
Impact Resistance 3 impacts (w/20N.m)
Min. Bend Radius 15 x cable diameter
Min. Bend Radius (Load) 20 x cable diameter
Compound Flow 30cm / 24h / 70 °C passed
Temperature Range Installation: -5°C to +50°C
operation: -20°C to +50°C
Storage: -20°C to +50°C
Number of Fibres 2 4 6 8 12 16 24
Max. Tensile Strength (N) 850 1000 1200 1500 2500 2700 3500
Nominal Weight (kg/km) 28 34 41 54 68 83 108
Cable Outer Diameter (+/- 0.5mm) 5.0 5.5 6.2 7.3 8.3 9.5 11.4
Outer Jacket Thickness (2-12, 16-24) 1.0+/-0.2mm 1.2+/-0.3mm
Standard Put-Up Length 2100m
One of important professional cablling system manufacturer and cabling solution servise provider in China. Hone technology has cooperated with China top telcommunication enterprises. Acumulated more than 30 years of reaserch and development experience.
Hone technology buits up manufacturer base more than 10000-sq. M in Sichuan and Zhejiang. The annual production is as follows: 3.5 million Pairs kilometers of optical cable, 70, 000 kilometers of coaxial cable, and 800, 000 boxes of digital LAN cable. Now Hone also make holding of a professional telecom euquipment manufacture who has kept independent innovation. Hone is providing more and more advantage telecom products.
At same time Hone technology experiences the high speed development of China telecommunication at past 20 years. With the development hone has grew stronger at the cabling solution servier. At present our project designer staff has 40 people at domestic. The projects extend to hostipal, gynasim, colleage, subway, goverment facilities with good reputation.
