Zhangjiagang Oriental Construction Material Co., Ltd. >> Indoor Wall Panel Wall Panel Decoration

Indoor Wall Panel Wall Panel Decoration

Name: Indoor Wall Panel Wall Panel Decoration
Brand: China-Manufacturer-Directory.com
SKU: 699976365
Availability: InStock
Rating: 4.4 (30 reviews)

Supplier:	Zhangjiagang Oriental Construction Material Co., Ltd.
Price:	US $ 3-25/Piece
Min Order:	100/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	OCM Mgo board
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color:	Gray, White, Pink, Green etc.
Density:	1.0-1.3G/Cm3
Edge:	Tapered,Beveled,Grooved
Surface Treatment:	Slurry, Nonslurry
Backside Treatment:	Texture and Sanded
Fire Resistant:	3 Hours
Delivery:	15 Days After Deposit
Certificates:	CE,ASTM ,SGS,ISO9001:2000 QC System
Sample:	Free Sample
Quality:	Grade a
Type:	Magnesium Oxide Board
Material:	Non-asbestos

Product Description

Indoor wall panel wall panel decoration

>Magnesium oxide board also called MGO board is manufactured by using special craft through totally automatic product line. The features being green.

>Composition
The materials of magnesium fireproof board are Magnesia(MGO), Magnesium Chlorid(Mgcl2)and Alkali glass fiber net

We offer wide range of the:
1. Standard Magnesium Oxide Board
2. Sanded Magnesium Oxide Board
3. Wood grain Magnesium Oxide Board
4. PVC coated MGO ceiling and Acoustic perforated Magnesium Oxide ceiling
5. Perlite board
6. Melamine/HPL laminated MGO board and UV laminated MGO board
7. MGO Sandwich Board /SIP for prefabricated house

>Main characteristic:
1. Fireproof-Grede A
2. Moisture resistant
3. Excellent impact resistant
4. Excellent sound insulation
5.100% no asbestos
6. Light weight and easy to work

>Size:
Thickness: 3mm-20mm
4'*8',
4'*9',
3'*6'
3'*7'
3'*8',
3'*9',
Edge: Square/Tapered/Beveled

>Technical Parameter
Will submit after further negotiation

Our MGO products range is including
1. Sanded MGO board
2. Wood grain MGO board siding
3. PVC coated MGO ceiling and Acoustic perofrated MGO ceiling
4. Perlite board
5. Melamine/HPL laminted MGO board and UV laminated MGO board
6. MGO Sandwich Board /SIP

TESTS / MATERIAL PROPERTIES
Compressive Strength	~20 MPa (3,000 PSI)
Impact Resistance	> 6 kJ/m2
Tensile Strength	> 5.5 MPa
Density (Specific Mass)	~1000 Kg/m3 (+/-<2%)
Moisture Absorption	~26% maximum saturation (slow absorption rate)
Moisture Content	~6%
Water Vapour Diffusion	~28 / 35
Specific Heat	~930 J/kgK
Thermal Conductivity	~0.44 W / mK
Modulus of elasticity	~6045 N/mm2
Flexibility UNI E 12372	~20.1 N/mm2 maximum 12mm x 1220 x 2440 = 10 N/mm2
Surface Alkalinity	~10 Ph
Thermal Expansion Hot/Cold	0,01 mm/mC (from temp +20C to -20C)
Expansion in Water	less than < 0.02% from ambient to saturation
Freeze / Thaw - UNI EN 520	100 cycles without notable effects
Frost Resistance	no water drops form on surface
Combustibility / Fire Ratings	non-combustible / 12mm exceeds 1 hr fire rating
Dimensional tolerance	thick 0.2mm / width 2mm / length 3mm / Sq. 3mm
Toxicity Pollutants Heavy Metals - UNI EN 12457-2	Below measurable levels of test instruments
Asbestos Analysis	Absent - not measurable
Formaldehyde Analysis	Absent - not measurable
Sound Attenuation (9mm)	tested design ASTM E90 = STC 48, 50, 55, & 60
Color	Slate Grey and Chalk White
Surface texture	smooth one side; uniform machine textured back
Basic Compounds	(MgO)+(natural silicates)+(glass fibre)+(wood fibre)

Zhangjiagang Oriental Construction Materials Co., Ltd. located in Zhangjiagang city, Jiangsu province, China. We are a comprehensive enterprise combining researching, manufacturing, processing and trading magnesium oxide products. Our factory name is Oriental Construction Material Industry Co., Ltd. It covers an area of 120, 000 square meters with annual production ability of 20, 000, 000 square meters.

Business scope:

We not only supply finished products including MGO board, MGO ceiling, decorative MGO board, MGO sandwich panel and fiber cement board. But also supply raw materials and technology. With 12 years manufacturing experience, we have successfully cooperated with clients in Brazil, UK, US, Australia, Bulgaria, Kazakhstan, South Africa and the Middle East.

Enterprise Culture:

We carry out the principle--Quality is the First, Client is the King, and Win-Win Cooperation. We are willing to develop together with the friends from all over the world.

Enterprise Offices:

Factory: N0.1 South Juxin Road, Juqiao Industrial Park, Zhangjiagang city, Jiangsu, China(Mainland)

Sales Office: Room 2703, Oriental Plaza, Zhangjiagang city, Jiangsu, China (Mainland)

Welcome you to visit us.
