| Supplier: | Shenzhen Hanzsung Technology Co., Ltd. |
|---|---|
| Price: | Negotiable/Piece |
| Min Order: | 1/Set |
| Quantity:: | |
| Trade Terms: | FOB,EXW,CIF |
|
|
| Prod Model: | NFD10 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Cooling: | Fanless |
| Range Of Application: | General |
| Application Field: | Industrial Control |
| Type: | Embedded POS |
| Processor Type: | Intel |
| Model No. | NFD10 | |
| Motherboard | ITX-M100_618 Hanzsung | |
| CPU | Integrated Intel ® 1037U 1.8GHz dual-core CPU TDP17W | |
| Chipset | Intel ® NM70 high speed chipset | |
| Graphics | Integrated Intel ® HD core Graphics , providing VAG \ HDMI | |
| System Memory | 1* SO DDRIII Memory Slot , Support 1066/1333 Memory, Max. up to 8GB | |
| Expansion Slot | 1* Mini-PCIE SLOT,Support WIFI/3G module | |
| Storage | 1* 2.5 ' SATA | |
| 1* MSATA slot,Support SSD \ WIFI | ||
| Network | Integrated Realtek Gigabit LAN chip,Supports Wake-on-LAN | |
| Front Panel Port | 1* COM port | |
| 2* USB 2.0 | ||
| 1*Line out | ||
| 1* Mic port | ||
| 1* POWER | ||
| Rear Panel Port | 4* USB 2.0 | |
| 5* COM | ||
| 1* HDMI | ||
| 1* VGA | ||
| 1* LAN | ||
| 1* Line out ( green ) | ||
| 1* Mic ( red) | ||
| 1* DC_12VIN | ||
| 1* WIFI antenna interface | ||
| Cooling System | Full enclosed and fanless ,cooling by chassis | |
| Operating Temperature | -0 C~ 50 C | |
| Storage Temperature | -20 C~ 70 C | |
| Operating Humidity | 5%-95%(relative humidity; non-condensing) | |
| Anti-vibration | 5 ~ 400Hz/random operating | |
| Form Factor | 210*220*50 (L*W*H/mm) | |
| Power Input | DC_12V single power input | |
| Installation | Desktop or wall mounting | |
| Material and craft | Sandblasting oxidation process (Black) | |
