Product Specifications
| Prod Model: |
EL780D05IG2 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Delivery Time: |
10-20day Depending on The |
| Cdrh: |
Class Iiia |
| Lifetime: |
>10, 000hrs |
| Laser Sight: |
Infrared |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Material: |
Element Semiconductor |
| Type: |
P-type Semiconductor |
| Package: |
Customized |
Product Description
1, Industrial quality
2, high stability
3, high reliability
4, low consumption
5, 780nm, 808nm, 830nm, 850nm and 980nm
Infrared Laser Diode Module EL780D05IG2
Elite could supply industrial infrared laser diode module with wavelengths listed below. It could be customized into different DOT, line or cross beams. The main feature is high stability, high reliability and long life span of more than 10, 000hrs. It could be applied in infrared lighting, military collimation, infrared surveying, medical usage, etc.
780nm 5mw ~ 3000mw
808nm 5mw ~ 5000mw
830nm 5mw ~ 3000mw
850nm 5mw ~ 3000mw
980nm 5mw ~ 5000mw
Low output power Series (DOT, Line, Cross)
EL780D05IG1, EL780D05IG2, EL780D05IG3, EL780D05IG4, EL780D05IG8, EL780D05IG9
EL808D05IG1, EL808D05IG2, EL808D05IG3, EL808D05IG4, EL808D05IG8, EL808D05IG9
EL830D05IG1, EL830D05IG2, EL830D05IG3, EL830D05IG4, EL830D05IG8, EL830D05IG9
EL850D05IG1, EL850D05IG2, EL850D05IG3, EL850D05IG4, EL850D05IG8, EL850D05IG9
EL980D05IG1, EL980D05IG2, EL980D05IG3, EL980D05IG4, EL980D05IG8, EL980D05IG9
Note: The difference of models listed is with different aperture and divergence. Some are suitable for short distance working (<2m), while some are suitable for far distance working (>50m). Please contact us, we will design a customized product especially suitable for your application.
Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.
Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.
Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.
Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
