Product Specifications
Prod Model: |
LBZ2500/2200/2000/1800/1600 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Type: |
Glass Washing and Drying Machine |
Certification: |
CE |
Control System: |
PLC |
Product Description
Product Name: LBZ2500 Vertical Insulating Glass Automatic Flat Press Production Line
Insulating Glass, Insulation Glass, Insulated Glass, Insulate Glass, Double Glazing, Double Glazed Glass, Double Glaze Glass, Hollow Glass, etc.
Functions characteristics:
Shape glass LOW-E insulating glass production line
Automatic control for LOW-E glass (2-brush treatment for LOW-E)
Automatic adjust function for pressing with hydraulic compression
Titling table with hydraulic pressure
Monitor using system temperature/speed/production volume
Mechanical trouble cheek
Whole line control function with 1 monitor
Technique parameter:
Max. Glass size 2500*3500mm
Min. Glass size 300500mm
Glass thickness 3-50mm
Thickness of washing glass UP TO 60mm
Max. In washing section 12m/min
Max. In accelerating 50m/min
Brush 4pair(LOW-E)
Power voltage 3p 41.5kw(380V)/50-60Hz
Size of line 25000*2560*3380mm
Power rate 20.6KW
