Product Specifications
| Prod Model: |
KTT-ITF46K |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Interactive Touch Foil: |
46 Inch |
Product Description
Kingtouch Technology is specialized in producing Interactive Projection touch foil/film through-glass, Surface Acoustic Wave(SAW) touch screen, WaterProof SAW Touchscreen, Dustproof SAW Touch Screen, Anti-glare, Vandal-proof SAW Touch Screen, Vandal-proof SAW TOUCH SCREEN, Multi-touch Infrared touch screen/IR Touch frame, LCD Touch Kiosk, Interactive touch foil, resistive touch screen, Touch LCD Monitor, LCD touch Panel PC/ Computer / bezel Monitor, Touch Tablet PC, Optical touch screen and Capacitive touch screen, Any size of touch panel we can customized for you. Just let us know the requirement. For Multi-touch IR Panel, we can offer Dual-touch(2 points), 6 points, 8 points, 10 points, 16 points and 32 points, No ghost point. etc.
Kingtouch Interactive Touch Foil are supplied with an electrostatic cling layer which makes them suitable for both permanent and temporary installations. The new improved touch foil have an upgraded driver with USB connection which has been digitally signed off by Microsoft (EMC approved) and are UL, FCC and CE approved (RoHS compliant). The Interactive Foils are combined with a screen technology to create an interactive touch screen display. Our main market for the Touch foils is 'thru-glass' interactive displays for store window applications, where the foil is combined with our range of projection films and high brightness LCD TFT screens. Such as interactive shop windows, trade shows, museums, meeting rooms and much more.
Standard Size of Interactive Touch Foil:
30inch to 114inch (4: 3 and 16: 9 ratio). All standard sizes are being shipped to dealers worldwide within one week (when in stock). Each touch foil comes with USB connector with cable Or RS232 Cable, driver software, installation video's and user guide.
HOW IT WORKS
Kingtouch's interactive touch foil can be combined with one of our rear projections foils or LCD displays. A rear projection foil is mounted, in combination of the touch foil, to the inside of shop window. Theprojected image on the projection foil can be seen from the outside. By the touch foil, the projection foil becomes interactive. In this way it is possible for the passer-by to interact with the shop window. This is just one of the many options that are possible with our through glass interactive touch foil.
Note:
Customizing sizes are available basic on the requirements for the customer, , please be free to contact us for more information.
Fixing Options:
1. Removable Option with Cling Film:
The touch foil is attached to a removable cling film for attaching to glass surfaces only. With this cling film you can carefully removing the touch foil from the glass and be re-used a number of times without damaging the touch foil. The cling film will be damaged and therefor not be usable
2. Permanent Lamination
Optically clear acrylic permanent adhesive is applied to the touch foil during manufacture and is therefor suitable for applying the touch foil to glass and acrylic. It is not possible to remove the touch foil without damaging it and being re-used.
3. Semi-Permanent Lamination
A special optically clear acrylic permanent adhesive is applied to the touch foil during manufacture for applying the touch foil to glass and acrylic. The interactive touch foil can be easily re-positioned during installation and removed without leaving a residue for up to 1 year. It is not possible to remove the touch foil without damaging it and being re-used.
4. No Fixing Option
It is possible to install the interactive touch foil without any fixing options. With this option you can use the touch foil where no fixing option is needed.
|
Detection Method: |
Projected Capacitance technology using horizontal vertical wires |
|
Screen Sizes: |
From: 30" , 40" , 50" 60" , 70" up to 100" . Available in 4: 3 & 16: 9 format. |
|
Position accuracy: |
Approximately 3 mm absolute, 1 mm relative. No drift |
|
Alignment: |
Software drivers provide a calibration facility |
|
Sensitivity: |
Adjustable by software. Can be programmed for different thickness of glass and even use with gloved hands. Functions with non-mertalise, single construction glass 16mm thick. |
|
Speed of response: |
Depends upon glass thickness. Typically 50 to 100ms. |
|
Output: |
RS232C communications to a 9 pin D female or USB Port |
|
Software Compatibility: |
Windows XP & Vista. |
|
Temperature range: |
Better than -10 to +70 |
|
Humidity Controller: |
0% to 95%. Unaffected by condensation |
|
Light Transmission: |
Depend upon glass thickness, typically better than 85% |
Kingtouch Technology Group Limited Was founded in 2003 in shenzhen from China. Kingtouch Technology is an organization of professionals dedicated to a complete line of the touch screen technology, development, manufactures and maketing with a highly skilled and innovative R&D group.
Kingtouch Technology Group Limited Had already build up and operating in accordance with ISO9001 Quality System and ISO14001 Environmental Management System. And Our products were certificated by FCC, CE, RoHS, ETL and UL. So Kingtouch Technology can provides the reasonable selection of touchscreen technologies and LCD touch monitor and also perfectly designs the requirements of the diverse applications the customer need, Such as POS, Kiosks, Office Automation, Transportation, Medical, Retail, Hospital and Game Machine, etc.
