IP Camera with Remote Monitor and Record Function for Home Security System

IP Camera with Remote Monitor and Record Function for Home Security System
Supplier: Shenzhen Niteray Electronic Co., Limited
Price: US $ 159/Piece
Min Order: 1/Piece
Quantity::
Trade Terms: FOB,EXW,CIF
contact supplier

Product Specifications

Prod Model: NR862
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Image Sensor: 30W Pixels CMOS
Signal System: PAL/PSTN
Video Resolution: VGA:640*480
Motion Detection: Yes
Alarm Input: Learning Wireless Sensor Alarm Input
Smoke Detect: Support
Email Alarm: Support
Video Record: Support
Video Call: Support
Special Features: Vandal-Proof
Type: IP Camera
Sensor: CMOS
Style: Dome Camera
Feature: Auto BLC
Technology: Infrared
Kind: Manual Focus Lens
Horizontal Resolution: 480tvl

Product Description

The NPC series is a type of excellent intelligent home product specially designed for digital field. It introduces embedded LINUX operating system which is more stable. It introduces the technology
Of standard H. 264 MP video compression format and G. 711A audio compression format which insure the high-quality image, low-bit rate and single frame playing. It introduces Cloudlink P2P network transmission technology which achieves strong network datatransmission ability and remote control ability. It introduces wireless learning codes technology and wireless detector to construct a strong alarm system.

Main functions:

Video call: It can realize the video call not only between two NPC, but also among smart phone, tablet computer and NPC.

Record function: After inserting U disk or Micro SD to NPC, it can realize simultaneous storage and recording of audioand video, and different recording mode such as manual recording, alarm recording, timing recording can be selected. You can search video files intelligent on the device and playback video on the screen directly.

Remote monitor: It can achieve remote monitor by using mobile APP to dial 3C number.

Wireless alarm: It introduces wireless learning code and wireless detector to construct alarm system, and also email alarm function is supported.
System Main processor High Performance Embedded Microprocessor  Hi3512
Operating system Embedded Linux OS
Video Image sensor 30W pixels  CMOS
Video Compression Format H.264
Signal System PAL/NTSC
Video Resolution VGA:640*480
Recording Speed VGA@ 25 fps  or  30 fps
Motion Detection YES
Minimum illumination 0 .1 LUX/F1.2
Video call YES
IR YES
Video  out put BT656/ 3.5 inch  TFT LCD
Audio Compression G.711A
Audio Input Built-in microphone or an external headset
Audio  Out put Built-in speakers or an external headset
Recording Manager Recording Mode Manual/Timer/Motion  /  Schedule
Video Storage USB, Micro SD
Alarm Alarm Input Learning wireless sensor alarm input
Alarm triggered Speakers alarm,Alarm recording,Capture,Email
Others Ethernet Interface RJ45    100M / 1000M Base-TX
USB  1*  USB 2.0
TF 1*TF
Wifi YES ,802.11 b/g/n
Headset One  3.5 headphone jack
Power Supply DC 5V 2A
PTZ Control Built-in horizontal and vertical control motor
Power Consumption 2W
Working Temperature 0°C-+55°C
Working Humidity 10%-90%
Dimensions ( mm ) 100*160*160mm
Weight 600g
Installation Rack mount

Shenzhen Niteray Electronic Co., Limited was set up in 2003. Develop, manufacturer and market Power Adapters, Power supplies and telephones for commerical and industrial usuage.

Equipped with specialized production lines, complemented by sophisticated quality control instruments, our products are guaranteed to meet internationally recognized standards, such as FCC, CE, UL, SAA and RoHS. We are striving to develop and manufacture the highest-grade products for clients worldwide.

Our main products contain
1) AC/DC adapters: 5W to 120W, wall mout plug and interchangeable plugs are our main products.
2) Mobile chargers: Approved chargers for all brands of mobile phone and iPod/iPhone.
3) Telephones: High quality corded telephone target for office, five star hotel, government and banks.

We are sincerely look forward to your continuous suport and to establish "Win/Win relationship!
