Product Specifications
| Prod Model: |
KH-AE668-12 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimension: |
88 X66 Mm (Front Panel) |
| Certification: |
FCC |
Product Description
216 Keys rugged Stainless Steel Numeric keypad with electronics controller protected by stainless steel housing, metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm, with rear mounting solution.
1. This Keyboard is mainly used for unsupervised or semi-supervised positions of varied access applications, internet terminals and information kiosks at universities, shopping malls, hotels, banks, airports, railway-stations and other public areas.
2. Ideal for applications in the harshest conditions, it meets NEMA 4, 4X and IP 65 specifications, making them vandal proof, resistant to dust, dirt, water and corrosive liquids.
3.7 Pin power terminals Interface, Matrix output; Also PS/2 or USB connector are available.
4. All international language lay-out are optional.
5. It is compatible to WINDOWS98/ME/2000/2003/XP/Vista/ Linux, UNIX, Mac OSX
MECHANICAL DATA
Keys: 12 keys, super quality SUS304 brushed stainless steel
Key top style: Protuberant rectangular keys, laser engraved & etched legends & raised braille on keys are available
Stroke travel: 0.5mm
Switch life: More than 1 million of per key
Panel: Made of 1.5mm thickness super quality brushed stainless steel
Customized layout is available
G. W.: 0.8 KGs
ELECTRICAL DATA
Supply Voltage: 5.0V DC± 5%
Current Rating: Appr. 30mA
EMC Standard: It is compliance with the council EMC directive 2004/108/EC
EN55022: 2006+A2: 2010
EN55024: 1998+A1: 2001+A2: 2003
Lifespan > 5 years
ENVIRONMENTAL ADAPTABILITY
Operating temperature: -20° C to +60° C
Storage temperature: -30° C to +70° C
Operating RH: 20-95%
Atmospheric pressure: 60-106Kpa.
RELIABILITY
RoHS Compliant, CE and FCC, ESD
Protection Level: IP65(front panel)
Vandal resistant: IK10
Key Lifespan > 10 million actuations
MTBF > 5, 0000H
MTTR < 30min
Shenzhen Kehang Technology Development Co., Ltd. is the domestic professional company engaged in development, production and sale of products using in finance and automotive industry. Our mainly products are: Finance self-service terminal keyboard, trackball mouse, self-payment device or enquire terminal, ATM/ADM/CDM self-service keyboard and mouse, and other industry-control computer, ruggedized computer, one industry working station, and some other computers using in industry.
We have a high experienced engineer team. We own a research and development and test centers and has relevant modern scientific research testing instruments to timely track advanced technology and develop new products for the customer.
Shenzhen Kehang Technology set up professional PCBA developers in research and development testing center in "Shenzhen Gaoqiao Industry Zone", there is a high device and electronic assembly factory. The company regards product quality as the basis of the enterprise and insists to execute the requirements of ISO9000 Quality Management System, apply six quality control tools to make sure product quality, analyze production and customer feedback data and achieve the standard demand of domestic and war industry.
Over the years, we have established a soft design and manufacture system to provide a products and solutions for customers based on their demands and environment.
We supply our customers for good products and solutions using in Finance, war industry, manufacture automotive, hospital, traffic, energy, communication, electric power, auto- industry, web and device set successfully. The company upholds the brand concept of "Good Products, Friendly Service" to help customers and sincerely welcome your wider and closer cooperation.
