Product Specifications
| Prod Model: |
DE |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size-1: |
72*72 |
| Size-2: |
96*96 |
| Accurancy: |
3.0 |
| Display Type: |
Analog |
| Showing Minutes: |
8 Min 5A/ 15min 5A/ 30 Min 5A |
| Phase: |
Three |
| Type: |
Analog Ammeter |
| Kind: |
Rotating Coil |
| Application: |
Electronic Equipment |
| Display: |
Indicator |
| Installation: |
Direct Connected |
| Theory: |
Electronic Meter |
| Power Source: |
AC Meter |
Product Description
High quality AC Current Meter Analog Ammeter
AC Specification:
Model: DE-T96, DE-T72, DE-T48, DE-C96, DE-C72, DE-C48
Accuracy: Class 1.5
Specs: 0.1A, 0.5A, 1A, 1.5A, 3A, 5A, 7.5A, 10A, 20A, 25A, 30A, 50A, 75, 100A(use Ext. CT 5A)
Note: For 60/75/100A direct meter, the class in 2.5.
Advantage: The scale can be easily changed without opening the front frame so that the class will not be influenced.
DC Specification:
Model: DE-C96, DE-C72, DE-C48
Accuracy: Class 1.5
Specs: 25uA, 30uA, 50uA, 1mA, 2mA, 5mA, 10mA, 20mA, 30mA, 50mA, 75mA, 100mA, 150mA, 200mA, 250mA, 300mA, 500mA, 1A, 3A, 5A, 7.5A, 10A, 20A, 30A, 50A, 75A,100A(use with shunt)
Note: For 60/75/100A direct meter, the class in 2.5.
Advantage: The scale can be easily changed without opening the front frame so that the class will not be influenced.
| Model | Unit | A | B | C | D | E | F |
| DE-96 | mm | 96 | 92 | 90 | 5.5 | 65 | 43 |
| DE-72 | mm | 72 | 68 | 66 | 5.5 | 65 | 43 |
| DE-48 | mm | 48 | 44 | 42 | 5.5 | 65 | 43 |
