Lin An Da Yang Welding Material Co., Ltd. >> ISO Approved Round Solid Rod

ISO Approved Round Solid Rod

Name: ISO Approved Round Solid Rod
Brand: China-Manufacturer-Directory.com
SKU: 730340775
Availability: InStock
Rating: 5 (24 reviews)

Supplier:	Lin An Da Yang Welding Material Co., Ltd.
Price:	Negotiable/Piece
Min Order:	500kgs
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	AWS E7015-A1
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Length:	300mm 350mm 400mm 450mm
Diameter:	2.0mm,2.5mm,3.2mm,4.0mm
Welding Current:	International Standard
Operating Temperature:	International Standard
Operating Current:	International Standard
Application:	Welding Carbon Steel Materials
Model Number:	E7015-A1
Delivery Detail:	Within 25 Days After Confirmation
Our Services:	Samples Are Provided for Free; OEM
Certificates:	with CE and ISO Approved
Type:	H (',Heat Resistant Low Alloy Steel/ Stainless Steel Electrode)
Function:	Hardfacing Electrode
Material:	Heat Resistant Steel

Product Description

Round Solid Rod / Steel Electrode (AWS E7015-A1)
Round Solid Rod / steel electrode is a kind of heat resistant steel welding electrode, which is applied to weld the covering of the boiler pipes (e.g.15Mo) after argon arc render with working temperature below 510°C. The solid rod can also be apply to weld general high strength low alloy steel.welding of boiler pipe line, working temperature of which is below 510oC, and also suitable for that of normal low alloy hing strength steel .

1. Details about the Round Solid Rod
Place of Origin: Zhejiang, China (Mainland)
Brand Name: Ocean Welding
Model Number: E7015-A1
Material: Steel Alloy
Length: 300mm 350mm 400mm 450mm
Diameter: 2.0mm,2.5mm,3.2mm,4.0mm
Application: Welding carbon steel materials

2. Descriptions
Pearlitic heat-resisting steel with coating of low sodium hydrogen electrode.DC reverse connection and all position welding.Workpiece shall be preheated about 150-250°C before welding and tempering at 620-710°C after welding process.

3. Features
1) Welding temperature is lower than 300 degrees

2) Heat-resistant-Steel-Electrode

4. Inner packing
1) 2.5mm x 300mm, 1-5kg/inner box + plastic bag
2) 3.2mm x 350mm, 1-5kg/inner box + plastic bag
3) 4.0mm x 350mm, 1-5kg/inner box + plastic bag

Mechanical Performance of deposited Metal(690±15°C×1H tempering)

Rm(Mpa)ReL(Mpa) A(%) Akw(J)

≥490 ≥390 ≥22 normal temperature

≥27

Deposited metal diffusion hydrogen content:≤6.0ml/100g (Method of glycerol)
X ray flaw detection requirement:LevelI

Reference Current:(DC)

Diameter (mm) Φ3.2 Φ4.0 Φ5.0

Current (A) 90-120 140-180 170-210

Notes:
(I)Please bake WER107 Heat-resistant Steel Electrode for 1 hour at about 350°C before welding.(II)Clean the surface to be welded thoroughly to remove surface contaminations.

Product Display

Package

How welding works?

Company Information
Lin'an Dayang Welding Material Co., Ltd., located in the western part of Hangzhou, was established at the beginning of this century. We possess a production line of oil pressure unit, which can produce 5000 ton stainless steel welding electrodes. Our company owns rich technical resources to design, research and mainly produce special type of electrodes with complete models.

The electrodes are mainly exported and the amount is up to 2000 tons per year on average. Our customers are mainly from Germany, Indonesia, Singapore, Philippines, Vietnam, Thailand, Bengal, and Egypt. They think highly of our products all the time.

In the days of 21st century, we will be stricter with ourselves and have continuous technical innovation which will spur us on to higher quality products for our users. Customers at home and abroad are sincerely invited to visit, call and hold talks on internet.

Heat-resistant Steel Electrode
Item NO.			GB/TB			AWS
WER107			E5015-A1			E7015-A1
Description: Pearlitic heat-resisting steel with coating of low sodium hydrogen electrode.DC reverse connection and all position welding.Workpiece shall be preheated about 150-250°C before welding and tempering at 620-710°C after welding process.
Application: WER107 Heat-resistant Steel Electrode apply to weld the covering of the boiler pipes (e.g.15Mo) after argon arc render with working temperature below 510°C.Can also apply to weld general high strength low alloy steel.
Chemical composition of Deposited metal(%):
C	Mn	Si	Mo	P	S	-	-	-
≤0.12	≤0.90	≤0.60	0.40-0.65	≤0.035	≤0.035
Mechanical Performance of deposited Metal(690±15°C×1H tempering)
Rm(Mpa)		ReL(Mpa)		A(%)		Akw(J)
≥490		≥390		≥22		normal temperature
						≥27
Deposited metal diffusion hydrogen content:≤6.0ml/100g (Method of glycerol) X ray flaw detection requirement:LevelI
Reference Current:(DC)
Diameter (mm)	Φ3.2			Φ4.0			Φ5.0
Current (A)	90-120			140-180			170-210
Notes: (I)Please bake WER107 Heat-resistant Steel Electrode for 1 hour at about 350°C before welding. (II)Clean the surface to be welded thoroughly to remove surface contaminations

Hangzhou Lin'an Dayang Welding Material Co., Ltd., located in the western part of Hangzhou, was established at the beginning of this century.

It possesses a production line of oil pressure unit, which can produce 1600 ton stainless steel welding electrodes.

The company owns rich technical resources to design, research and mainly produce special type of electrodes with complete models.

The electrodes are mainly exported and the amount is up to 800 ton per year on average. The customers are mainly from Germany, Indonesia, Singapore, Philippines, Vietnam, Thailand, Bengal, Egypt, etc. and they think highly of our products all the time.

In the days of 21st century, we will be stricter with ourselves and have continuous technical innovation which will spur us on to higher quality products for our users.

Customers at home and abroad are sincerely invited to visit, call and hold talks on internet.
