Isuzu Engine Diesel Engine (Isuzu 4BD1 4BD1T)
Product Specifications
| Prod Model: |
Isuzu 4BD1 4BD1T |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Delivery Detail: |
20days |
| Fuel: |
Diesel Engine |
Product Description
We provide you the Full series of the Isuzu diesel engine, which produced under the Isuzu technology.
Isuzu engine Diesel Engine (4ja1 4jb1 4jb1t 4bd1 4bd1t 6bd1 6bd1t)
ISUZU / Nissan engine
Engine modelcylinder bore*stroke (mm)displacement (L)Rated power/speed (kw/r/min)Peak torque/speed (N. M/r/min)Idle speed (r/min)Weight (kg)
Monarch power limited
4BD14102*1183.85670.6/3200245/2200650-750330
4BD14102*1183.85674/3000265/2000650-750330
4BD1T4102*1183.85688/2800343/1600650-750340
4BD1T4102*1183.85681/2800323/1600650-750340
4BD1T4102*1183.85674/3000265/1800650-750340
6BD16102*1185.78573/2200353/1600700480
6BD16102*1185.78581/2500353/1700700480
6BD1T6102*1185.785107/2800420/1600-1800700-750555
6BD1T6102*1185.785114/2800431/1600-1800700-750555
6BD1T6102*1185.785120/2800480/1600-1800700-750555
6BD1T6102*1185.785132/2600560/1400-1800700-750555
4HF14112*1104.344110/2600460700-750365
4JB1493*1022.771L55/3600172/2200790235
4JB1T493*1022.771L65/3600202/2200830240
4JA1493*922.44950/3600176/2000230
QD32T499.2*1023.15380.9/3600221/2000750-800272
Nissan QD32TI499.2*1023.15396/3600280/2000750-800275
Nissan QD32TI499.2*1023.153101.5/3600313/2000750-800275
| Engine model | ISUZU 4BD1 | ISUZU 4BD1T |
| Type | vertical in line ,water cooled,
4 stroke,natural aspiration | vertical in line ,water cooled,
4 stroke,Turbocharged |
| No.of Cylinder | 4 | 4 |
| Bore/stroke (mm) | 102x118 | 102x118 |
| Displacement (L) | 3.856 | 3.856 |
| Injection type | direct injection | direct injection |
| Compression ratio | 17.5:1 | 17:01 |
| Rate power (kw/r/min) | 70.6/3200 74/3000 | 88/2800, 81/2800, 74/3000 |
| Max torque/speed (N.m/r/min) | 245/2200 265/2000 | 343/1600, 323/1600, 265/1800 |
| Min fuel consumption (g/kw.h) | ≤221 | ≤215 |
| Idle speed (r/min) | 650-750 | 650-750 |
| Oil consumption (g/kw.h) | ≤1.63 | ≤0.8 |
| igniter order | 1-3-4-2 | 1-3-4-2 |
| Sound class dB(A) | 115 | 114 |
| Net weight (Kg) | 330 | 340 |
| Overall dimension (mm) | 820X651X751 | 820X660X813 |
| ISUZU / Nissan engine |
| Engine model | cylinder | bore*stroke (mm) | displacement (L) | Rated power/speed (kw/r/min) | Peak torque/speed (N.m/r/min) | Idle speed (r/min) | Weight (kg) |
| Monarch power limited |
| 4BD1 | 4 | 102*118 | 3.856 | 70.6/3200 | 245/2200 | 650-750 | 330 |
| 4BD1 | 4 | 102*118 | 3.856 | 74/3000 | 265/2000 | 650-750 | 330 |
| 4BD1T | 4 | 102*118 | 3.856 | 88/2800 | 343/1600 | 650-750 | 340 |
| 4BD1T | 4 | 102*118 | 3.856 | 81/2800 | 323/1600 | 650-750 | 340 |
| 4BD1T | 4 | 102*118 | 3.856 | 74/3000 | 265/1800 | 650-750 | 340 |
| 6BD1 | 6 | 102*118 | 5.785 | 73/2200 | 353/1600 | 700 | 480 |
| 6BD1 | 6 | 102*118 | 5.785 | 81/2500 | 353/1700 | 700 | 480 |
| 6BD1T | 6 | 102*118 | 5.785 | 107/2800 | 420/1600-1800 | 700-750 | 555 |
| 6BD1T | 6 | 102*118 | 5.785 | 114/2800 | 431/1600-1800 | 700-750 | 555 |
| 6BD1T | 6 | 102*118 | 5.785 | 120/2800 | 480/1600-1800 | 700-750 | 555 |
| 6BD1T | 6 | 102*118 | 5.785 | 132/2600 | 560/1400-1800 | 700-750 | 555 |
| 4HF1 | 4 | 112*110 | 4.344 | 110/2600 | 460 | 700-750 | 365 |
| 4JB1 | 4 | 93*102 | 2.771L | 55/3600 | 172/2200 | 790 | 235 |
| 4JB1T | 4 | 93*102 | 2.771L | 65/3600 | 202/2200 | 830 | 240 |
| 4JA1 | 4 | 93*92 | 2.449 | 50/3600 | 176/2000 |
| 230 |
| QD32T | 4 | 99.2*102 | 3.153 | 80.9/3600 | 221/2000 | 750-800 | 272 |
| Nissan QD32TI | 4 | 99.2*102 | 3.153 | 96/3600 | 280/2000 | 750-800 | 275 |
| Nissan QD32TI | 4 | 99.2*102 | 3.153 | 101.5/3600 | 313/2000 | 750-800 | 275 |
Shanghai Monarch Power Engineering Limited has already established very close relationships with Cummins, Deutz, Isuzu, Lovol, Iveco, Nissan, Toyota and other manufacturers. We can also provide you with the complete series of engines with the brands above. The engines are used for marine propulsion, marine generators, industrial generators, construction engines, vehicle engines, agriculture engines, etc.
We has already established cooperation relationships with customers all over the world, with an experienced and professional staff group, as well as senior engineers, technicians and salesmen. Now our company is known as a leading manufacturer in supplying of diesel generators (for both industrial use and marine use).
We can provide you with generators which are approved by China Classification Society CCS. Our marine generator can be approved by CCS, ABS, BV, DNV, GL, LR, GL, RS, etc. With steady quality, quick and professional service, our company gains the general recognition from users at home and abroad.
We are sincerely looking forward to establishing business relationships with you for our mutual benefit.
Products of Monarch Power Limited dealing with
1) Diesel engine: CUMMINS B, C, ISBe, ISDe, ISLe, L, ISF2.8/3.8 and DEUTZ BFM1015, FL413 & FL513, TBD234 and 226B for vehicle; CUMMINS B, C, KTA, N and DEUTZ TBD234, 226B for marine; CUMMINS B, C and DEUTZ FL413&FL513, FL912&913, TBD234 and 226B for genset; CUMMINS B, C, M11 and DEUTZ FL413&FL513, FL511, FL912&FL913, 226B, BF4M1013&BF6M1013, BF1015, TBD234 for industry.
2) Engine spare parts and machinery components: Genuine, OEM and aftermarket parts for the CUMMINS, DEUTZ, KOMATSU and some Japanese serial car. Genuine and Chinese-made machinery parts for the heavy mchine. Cummins Marine Engine Parts.
3) Generator set: CUMMINS diesel generator set for landuse and marine; CUMMINS natural gas and biogas generator set. DEUTZ diesel generator set
Monarch Power Limited welcome to customers from all around the world to visit and expect to build long and friendly business relations with you and your company in the near future!
