Kc050aro, Thin-Wall Angular Contact Ball Bearing, Diesel Engine

Kc050aro, Thin-Wall Angular Contact Ball Bearing, Diesel Engine
Supplier: Luoyang Lirui Bearing Co., Ltd.
Price: US $ 0.1/Piece
Min Order: 1/Piece
Quantity::
Trade Terms: FOB,CFR,CIP
contact supplier

Product Specifications

Prod Model: KC050ARO
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Inner Diameter: 127 Mm
Outer Diameter: 146.05 Mm
Breadth: 9.525 Mm
Weight: 0.263 Kg
Rolling Body: Ball Bearings
Separated: Unseparated
The Number Of Rows: Single
Outer Dimension: Medium and Large(',120-190mm)
Load Direction: Radial Bearing
Material: Bearing Steel

Product Description

Angular contact ball bearings

Contact Angle between ring and ball, standard of contact Angle is 15 ° , 30 ° , and 40 °
The larger the contact Angle is, the larger axial load capacity will be.
The smaller the contact Angle is, the more conducive the high-speed rotation will be.
Single-row bearing can withstand radial load and one-way axial load.
DB combination, DF combination, and double-row bearings can withstand radial load and two-way axial load.
DT combination is suitable for occasion, like one-way axial load is greater, and the lack of rated load for a single bearing.
High speed with ACH type bearings are mostly used for machine tool spindle, of which the ball diameter is small and numerous.
Angular contact ball bearings are suitable for high speed and high precision rotation.

Main Use:
Single-row: Machine tool spindle, high frequency motor, gas turbine, centrifugal separator, small car front wheel, differential pinion shaft
Double-row: Oil pump, roots blower, air compressor, all kinds of transmission, fuel injection pump, printing machinery.

Packaging & Delivery
Packaging details:
1, wooden boxes
2. Be oiled and wrapped with water-proof belt
3. Wooden pallets
4. According to customers requirement
Delivery Detail:
2-5 days for stock bearing, 40-60 days for future goods

Specifications
1. Reasonable price
2. Various types
3. Quick delivery
4. OEM service

Product Specification:
1. Series: Angular Contact Ball Bearing
2. Cage: Machined brass cage,
3. Material: GCr15/GCr15SiMn
4. Precision: P0
5. Quality: IS09001: 2000
6. Packing: Standard export packing & industry packing & according to clients' requirement.
7. Brand: LRZ
8. Origin city: Luoyang of China
9. MOQ: 2 pcs
10. Delivery term: FOB Shanghai port & CIF
11. Others OEM orders available

Type
Major dimensions
weight
Rated loading Limiting speed Equivalent
d D      B radial thrust
static dynamic static dynamic SILVERTHIN
In Mm In Mm in mm kg Co(N) Cr(N) Co(N) Cr(N) (RMP)
KC040ARO 4 101.6 4.75 120.65 0.375 9.525 0.204 11340 6270 32740 18150 4570 SC040ARO
KC042ARO 4.25 107.95 5 127 0.375 9.525 0.213 12050 6410 34790 18590 4320 SC042ARO
KC045ARO 4.5 114.3 5.25 133.35 0.375 9.525 0.218 12720 6540 36790 18950 4100 SC045ARO
KC047ARO 4.75 120.65 5.5 139.7 0.375 9.525 0.227 13430 6670 38790 19310 3900 SC047ARO
KC050ARO 5 127 5.75 146.05 0.375 9.525 0.263 14150 6850 40790 19790 3720 SC050ARO
KC055ARO 5.5 139.7 6.25 158.75 0.375 9.525 0.268 15300 6940 44130 20190 3400 SC055ARO
KC060ARO 6 152.4 6.75 171.45 0.375 9.525 0.286 16680 7210 48130 20860 3140 SC060ARO
KC065ARO 6.5 165.1 7.25 184.15 0.375 9.525 0.308 18060 7430 52130 21480 2910 SC065ARO
KC070ARO 7 177.8 7.75 196.85 0.375 9.525 0.331 19220 7650 55470 22150 2710 SC070ARO
KC075ARO 7.5 190.5 8.25 209.55 0.375 9.525 0.354 20600 7780 59520 22640 2540 SC075ARO
KC080ARO 8 203.2 8.75 222.25 0.375 9.525 0.381 22020 8010 63520 23180 2390 SC080ARO
KC090ARO 9 228.6 9.75 274.65 0.375 9.525 0.426 24550 8270 70860 24020 2130 SC090ARO
KC100ARO 10 254 10.75 273.05 0.375 9.525 0.481 27310 8640 78870 24780 1930 SC100ARO
KC110ARO 11 279.4 11.75 298.45 0.375 9.525 0.526 29890 9110 86250 25710 1760 SC110ARO
KC120ARO 12 304.8 12.75 323.85 0.375 9.525 0.567 32430 9550 93590 26600 1620 SC120ARO
KC140ARO 14 355.6 14.75 374.65 0.375 9.525 0.689 37770 10440 108980 28160 1390 SC140ARO
KC160ARO 16 406.4 16.75 425.45 0.375 9.525 0.785 43060 11270 124330 29940 1220 SC160ARO
KC180ARO 18 457.2 18.75 576.25 0.375 9.525 0.88 48400 12040 139720 32380 1090 SC180ARO
KC200ARO 20 508 20.75 527.05 0.375 9.525 0.98 53510 12740 154440 34610 980 SC200ARO
KC250ARO 25 635 25.75 654.05 0.375 9.525 1220 62280 14380 192520 40080 790 SC250ARO
KC300ARO 30 762 30.75 781.05 0.375 9.525 1456 79890 15840 230640 45190 660 SC300ARO
Luoyang Lirui Bearing Co., Ltd, located in an ancient capital city Luoyang which is a great production base for bearing, is a new-high technology corporation with the integration of design, research and development, manufacturing. Our company is based on not only the development of China's bearing, but also the global perspective, and has first-class team of bearing experts and engineers, the domestic first-class CNC grinding, automatic equipment, and large-scale sophisticated equipment, all of these guarantee that our bearings have high precision and stability.

Our company has been found in 1994, since the establishment, we inherit "honest and trustworthy, the user orientated", adhere to high quality pre-sales technical support, superior product quality coupled with excellent after-sale service to serve every customer. We are specialized in the design, research and production to various non standard bearing, imported substitution bearing and special bearing, which are widely applied to aerospace, precision instruments, textile, precision lathe, port, mining, medical treatment, coal, cement, oil drilling, wind power generation, industrial robots, defense industry and other fields. A large number of our products are exported to the United States, Britain, Canada, Germany, Austria, Italy, Japan, Korea, Singapore, India, Pakistan, Thailand, Malaysia and other countries.

We have got ISO9001: 2000 certificate, as it is represented in "Quality Guideline", Lirui bearing focus on comprehensive quality management, and take it as a sustained effort to improve customer satisfaction. These requires our team including senior management take on the job training and further education. At the meantime, it is necessary to establish full assessment to ensure that this goes smoothly in this area. The company gradually forms a stable country and worldwide sales network. Each product reflects constant pursuit of the excellence of Lirui employees, and serves our customers by qualified products and business philosophy of "innovation, integrity and pragmatic, development". Creating value for customers and guarantee satisfaction to the customers are our principles, thus, we sincerely welcome friends from all over the world come to discuss, exchange and cooperation. Let us use our joint hands to create a bright future.
