Conductor material:Aluminum
Ambient temperature:--25~50(ºC)
Conductor material:Copper
Pluggable times:500000 times
Power frequency:50-60(HZ)
Rated current:30A
· Description: 15 Amp, 125 Volt, NEMA 5-15P, 2P, 3W, Plug, Straight Blade, Grounding
· Color: Black
· Rating: 15A, 125VAC
· NEMA: 5-15P
· Pole: 2
· Wire: 3
· Dielectric Voltage: Withstands 2000V per UL498
· Body Material: Thermoplastic PVC
· Blade Holder: Thermoplastic Nylon
· Blades/Contacts: Brass
CODE COMPLIANCE
· UL 498 comply
· ROHS comply
MATERIAL CHARACTERISTICS
· Environmental: Flammability, UL-94, Rated V0
· Operating Temperature: -40° F to 149° F (-40° C to 65° C)
FEATURES
· Solid brass plug blades are firmly embedded in body
· Terminal screw clamp are designed to contain wire and prevent binding
· Terminal screws backed out-ready for wiring
· Terminals in individual chambers to positively insulate conductors
· Armored housing automaticaly grounded
· Limited Two-Year Warranty
Description: 30 Amp, 125/250 Volt, NEMA 14-30R, Surface Mounting Receptacle, Industrial Grade
· Color: Black
· Rating: 30A, 125/250VAC
· NEMA: 14-30R
· Pole: 3
· Wire: 3
· Dielectric Voltage: Withstands 2000V per UL498
· Face Material: Thermoplastic PC
· Body Material: Thermoplastic PC
CODE COMPLIANCE
· UL 498 comply
· ROHS comply
MATERIAL CHARACTERISTICS
· Environmental: Flammability, UL-94, Rated V0
· Operating Temperature: -40° F to 149° F (-40° C to 65° C)
FEATURES
· Terminal screws accept up to No. 12 AWG copper or copper-clad wire
· Quickwire push-in terminals accept No. 14 AWG solid copper wire only
· Double-wipe power contacts for reliable conductivity and plug retention
· Impact resistant thermoplastic construction
· Heavy-gauge, rust resistant steel mounting strap
· Double-wipe ground contacts ensure long-term ground retention
· Tri-Drive ground, terminal and mounting screws ease installation
· Captive mounting screws
· Limited Two-Year Warranty
![]()
