Product Specifications
| Prod Model: |
FT2512 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Quotation Valid: |
with in 30 Days |
| Delivery Time: |
According to Customers' Requirements or 2-3months |
| MOQ: |
According to Customer's Request |
| Door To Door: |
Accept |
| Payment Term: |
L/C& T T, or Based on The Negotiation |
| Certificate: |
ISO9001, CE |
| OEM: |
Acceptable |
| Place Of Origin: |
Liaoning, China |
| Third Party Inspection: |
Accept |
| Supply Ability: |
300sets/Year |
| Color & Page: |
Multi-Colour Printing Press |
| Printing Interface: |
USB2.0 |
| Plate: |
Digital Inkjet Printing |
| Structure: |
Flatbed |
| Usage: |
Multipurpose |
| System Supported: |
Windows 7 |
| Printing Speed: |
15-72 Sqm/H |
Product Description
Technical features:
Sky Air-Ship Digital Printing Equipment Co.,ltd. is the pioneer of manufacturers of UV flatbed printers in China. With remarkable reputation and very high cost performance, Skyjet UV flatbed printers have been sold more than 600 units both in China and more than 40 countries in the world in the past 7 years, Skyjet has been the No.1 seller of UV flatbed printer in China.
FT2512 is a high cost performance UV flatbed printer with stable printing and various special applications for white color, varnish and primer, which is widely used by customers from different fields.
l. High speed printing: 16 pieces of KM1024MH print heads can realize 72 sq.m/h under 4 pass
2. 9 colors technology: CMYK LC LM White Varnish Primer, unique primer printing function is the best feature for printing on glass and ceramic tile
3. Stable printing: real Konica Minolta print head with heater and sensor inside, the temperature inside the print head is very stable, which realize best condition for ink ejecting and make sure the stability of printing.
4. Three layer printing: special technology of controlling print heads to realize "color-white-color" and "white-white-color" 3D printing.
5. Dual white printing: remarkable dual white printing technology
6. White printing: with best rip software caldera, many applications for white color such as overlay white, underlay white, fill white and spot white can be adopted on transparent materials to realize elegant appearance.
7. The carriage can start printing at either end on Y-direction, that is, it can print forwards and backwards, saving much time and raising productivity to a great extent
8. Automatic height detection: the maximum print thickness is 100mm, the height can be adjusted to appointed position automatically.
9. Automatic capping device: practical capping device ensures convenient maintenance
l0. Special sectional vacuum suction: separate sectional vacuum suction effectively avoid print materials getting twisted.
11. Stop valve: Practical stop valves are installed in the carriage to prevent ink from dropping, electronic valves are also available
12. Locating pin: locating pins can be installed on the table of the printer for aligning, vertical printing and repeat printing are very convenient.
13. Anti-static function: anti-static device can be installed on the printer to eliminate static, misting can be avoided.
14. Anti-crash design: it can avoid any accident caused by carriage crash, effectively protect print heads.
15. UV light shield design: effectively protect operator
16. Constant temperature in the ink tank: making sure it can print in a cold room.
17. Pneumatically controlled waste ink container
Technological advantages:
Skyjet provide one-stop digital printing technological solutions for different fields such as electrical panel, art glass, decorative ceramic tile, furniture and so on.
Application fields:
It is suitable for printing all kinds of materials, rigid materials such as glass, ceramic tile, ceiling, aluminum board, wood board, door, label, acrylic, KD board, Plexiglas, foam board, corrugated paper, and so on. Flexible materials such as wallpaper, tapetum lucidum, canvas, carpet, leather, paper, PVC and so on.
FT2512 Technical parameters:| Model | FT2512C | FT2512H |
| Print width | 2500X1230mm |
| Maximum thickness | 100mm |
| P.H.type | KM512 | KM1024 | KM1024 |
| Number of P.H. | 4 ,5,6,7,8,9, | 4 ,5,6,7,8,9, | 8,10,12,14,16 |
| Print speed | Draft model | 18M2/h | 36 M2/h | 72 M2/h |
| Normalmodel | 12 M2/h | 24 M2/h | 48 M2/h |
| High precision | 9 M2/h | 18 M2/h | 36 M2/h |
| Color configuration | C,M,Y,K,Lc,Lm,W ,V,P |
| PIP software | SEEGET/ONYX/CALDERA |
| Power supply | Single phase AC220V/3000W |
| Environmental requirement | Temperature 2-28 degree centigrade,romm humidity 40%-60% |
| Dimension | 4340mm x2100mm x1430mm |
| Packaging Details | Packed in wooden case |
| Delivery Detail | According to customers' requirements or 15-20days |
Sky Air-ship Digital Printing Equipment Co., Ltd is one of pioneers who specializes in research and development of digital printing equipments in China. We have been approved as the high and new technology enterprise by state. As the printing technology developer, we have much technology patents, especially in wide format outdoor digital printing. "SKYJET" printer adopts a unique cylinder & arch-shaped printing structure, which is equipped with synchro double-side printing function. It is the exclusive type of printer that is applied for national patents on transmission structure as well.
"SKYJET", as the trademark of Sky Air-ship Company, has become the most famous brand by the effort through all SKYJET staff in 16 years. In 2008, "SKYJET" is authoritatively assessed the first session of "Chinese Printers Top Ten Brands". It is conferred as the "Golden Kylin Award" by InkJet Printing Sub-Association of PEIAC and Inkjet Printing Association of China. Furthermore, Sky Air-ship Company wins the medal of "Excellent Exports Enterprise". As the member of council of Sub-association of Inkjet Printing Association of China, Sky Air-ship Company participates in drafting out "National Standard of the Chinese Wide Format Digital Printing & Press Machine" and we have awarded two famous certification: ISO9001 Quality Management System Certification and CE certificate.
Sky Air-ship Company, occupying 12000 square meters as the manufacturing base, has more than 150 employees. We have strong R & D team, which leads to more than ten exclusive patents technology and independent production ability, and cooperates with international companies. As the professional, productive and creative printing equipment manufacturer, "SKYJET" has been praised by all the customers around the world. SKYJET UV Flatbed Printer has the largest market share among the similar products in China. SKYJET has exported all series of printers to more than 50 countries, including USA, Western and Eastern Europe, Asia-Pacific, South America, Africa, etc.
