Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Field of application
It is applied to quick cutting all kinds of sheet metal plate, such as stainless steel, carbon steel, manganese steel, carbide alloy steel, etc.
Mainly used in quick cutting substrate of diamond saw blade, cutting noise-ilent trough of the substrate of diamond saw blade.
Feature
1. Lower electricity cost, total power only 7kw/h when machine in normal cutting
2. Lower assistance gas cost, blowing compressed air, O2, N2 suitable all kinds of the cutting process
3. High performance qualified resonator, Complete import or assembly with foreign famous brand parts which is high reliability and longevity of service. Max life reach to more than 100000hours.
4. High speed cutting, Max cutting speed reach to 10m/min in cutting 1mm carbon steel
5. Maintenance free resonator
6. Smooth cutting surface, small deformation, pretty leveling appearance
7. Adopt variable focus length perforation technology, working efficiency reached 2 times than traditional process.
8. Double exchange working table save loading time
9. Adopt import transmission parts and servo motor, high dynamic movement performance, high cutting precision
10. Easy operation
|
No. |
Item |
Parameter
|
|
1 |
Laser wave length |
1064nm |
|
2 |
Max laser power |
Fiber 2000W |
|
3 |
Pulse frequency |
1~00Hz Continues adjustmen |
|
4 |
Aim positioning |
Red light instruction |
|
5 |
Cutting scope |
1500mm*1500mm |
|
6 |
Max positioning speed |
120m/Min |
|
7 |
X/Y axie repositioning accuracy |
± 0.01mm |
|
8 |
Max thickness cutting material |
Stainless ≤ 10mm; steel≤ 16mm |
|
9 |
Graphic format |
DXF Auto CAD |
|
10 |
Total power |
≤ 40KW |
|
11 |
power supply requirement |
3 phase 380V, 0Hz, 0A |
|
12 |
(L× W× H)Main machine outline dimension |
6500mm*3500mm*2200mm |
