Laser Diode Module with Wide Work Temperature

Name: Laser Diode Module with Wide Work Temperature
Brand: china-manufacturer-directory.com
SKU: 708662475
Availability: InStock
Rating: 4.7 (93 reviews)

Supplier:	Elite Optoelectronics Co., Ltd.
Price:	Negotiable/Piece
Min Order:	100/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Max. Forward Voltage:	3VDC
Max. Forward Current:	30mA
Lifetime:	>10, 000hrs
Delivery Time:	10-20day Depending on The Qty
Manufacturing Technology:	Optoelectronic Semiconductor
Material:	Element Semiconductor
Type:	P-type Semiconductor
Package:	Customized

Product Description

1, High quality industrial laser diode
2, APC driving circuit
3, Low cost
4, High reliability
5, Long Life

Industrial Laser Modules
1, High quality industrial laser diode
2, APC driving circuit
3, Low cost
4, High reliability
5, Long Life

Application:
1. Industrial Instruments and Equipments
2. Wild Explore Instruments
3. Military Instruments and Equipments
4. Medical Instruments

Notes:
1) Part of the laser module could be worked at 60-70° C
2) Power Stability was defined as the power output shift at the operating voltage or temperature changing process
3) Operating Voltage also could be 9 ~12VDC
4) High power output red laser module have 110VAC or 220VAC power adapter

Specifications
Spectral Range	Red		Infrared
Wavelength(nm)	635	650	780	808	850	980
Output power(nW)	5~40	5~150	5~150	100~30000	5~100	50~7000
Operating current(mA)	25(min)~5000(max)
DC Input Voltage (V)	2.6~5.5
Operating Temperature( Deg.C )	From -10 to 50
Storage Temperature ( Deg. C)	From -40 to 80
Power Stability via Operating Voltage	>95% ( @2.7~5.5VDC)
Power Stability via Operating Temperature	>90% (@-10°C~50°C)
MTTF (Hrs)	10000
Circuit Protection	Static, Surge, and Reverse Polarity Protected
Case Material	Brass or Aluminum
Output Beam	Dot, Line & Cross		Dot

Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.

Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.

Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.

Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
