Product Description
Laser Engraving Machine with Up-down TableGA -S1280
Model: GA-S1280 (With motorized up-down table rotary attachment)
Specification: 1200× 800mm
Product Name: Motorized up-down table laser engraver
Product Type: GA-S Series Motorized laser machine
Item Number: GA-S1280
Processing Area: 1200× 800mm
Introduction
1. The up-down work table design satisfies the customers' need of engraving thick materials.
2. The design of motorized up and down table and rotary attachment is ideal for engraving cylinders, bottles and thick materials.
3. The front and back running-through design, suitable for extra-length material process.
4. Hermetic exhausting system with unfixed exhausted kit, thoroughly resolves waster air exhausting problem from the laser processing and fulfills the related process requirements.
Optional attachments
Red DOT pointer, auto-focus.
Technical lndex:
Processing Area: 1200× 800mm
Ascending and descending distance: 200mm/ 300mm
Laser Power: 60/80W
Max. Cutting speed: 36000mm/min
Max. Engraving speed: 64000mm/min
Electro motion ascending and descending weight: 20KG
Resolution Ration: 0.0064mm
Minimum shaping character: Chinese Character: 2× 2mm, letter: 1× 1mm
Location precision: <0.01/mm
Power supply: AC220± 10% 50Hz (can be changed).
Gross Power: 1100W
Graphic format supported: BMP, PLT, AI, DXF, DST, GIF and so on;
Applicable industries:
Cylinders engraving and nonmetal materials cutting for advertising, decorative, crafts and gifts, model industries etc.
Applicable materials
Acrylic, MDF, plywood, bamboo products, color plates, fabrics, paper, leather, shellfish, coconut shell, horn, resin, animal skin, ABS boards, lamp etc.
