Features:
0.15mm minimum line foot-ath (interval)
Min. Aperture: 0.3mm
He largest area of processing is a form of 600 X 800mm
Layer: 2
Board technology: HASL
Gerber files of bare PC board
Dimensional specifications for non-standard components
Assembly drawing including any change notices
Final test procedures
In order to shorten lead time, please advise us acceptable components for substitute.
OEM orders are welcome.
1 layer
1-12 layer
2 Material
FR-1, FR-2, FR-4, CEM-1, CEM-3, Hight TG, FR4 Halogen Free,
3 Board thickness
0.2mm-7mm
4 Max panel size
630mm*520mm
5 Min. Drilled hole size
0.25mm
6 min. Line width
0.075mm(3mil)
7 min. Line spaceing
0.075mm(3mil)
8 Surface finish/treatment
HALS/HALS lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, OSP, Gold Plating
9 Copper thickness
0.5-4.0oz
10 Solder mask color
Green/black/white/red/blue/yellow
11 Inner packing
Vacuum packing, Plastic bag
12 Outer packing
Standard carton paCking
13 Hole tolerance
PTH: ± 0.076, NTPH: ± 0.05
14 Certificate
UL, ISO9001, ISO14001, ISO/TS16949, RoHS
15 profiling punching
Routing, V-CUT, Beveling
16. Providing you one-stop PCB assemblies service.
Product Specification/Models
Component procurement coming from local approval supplier and oversea agent and manufacturer
Stock control and warehousing
Production (SMT, DIP, final assembly, package)
Three ovals LED used
Quality control and test
Packaging and dispatch
Added benefits to using a turnkey solution
Facilities marketing objectives
Reduces inventory
Cost-effective
Just-in-time (jit) delivery
Information is requested for this service:
Gerber files of bare PC board
Dimensional specifications for non-standard components
Assembly drawing including any change notices
Final test procedures
In order to shorten lead time, please advise us acceptable components for substitute.
OEM orders are welcome.
Leadsintec Co., Ltd., is an electronics manufacturing services (EMS) provider. Based in Shenzhen China, We have been specializing in PCB assembly over the past 5 years. We have served well-known OEM buyers worldwide which put their focus on market and design etc, Leadsin offers total solution to customers'manufacturing needs., Our customers mainly including companies from Consumer, security and safety, industrial, medical, Network, automation, measurement, counter device sectors and so on, Some products we made are often requested to operate in harsh or hostile environments when quality and reliability are critical, according to the years' experience, we have gained reputation with reasonal cost and wide source, on time delivery in the electronic production field.
Our manufacturing facilities include clean workshops and high speed advanced SMT lines. Our placement precision can reach chip +0.1MM on integrated circuit parts, which means we can almost deal with all kinds of integrated circuits such as SO, SOP, SOJ, TSOP, TSSOP, QFP, BGA and U-BGA. Additionally, we can provide 0201 chip placement, through-hole components insertion, and finished products fabrication, testing, package.
Our capability and services range
1. Production of customer designed components
2. SMD assembly and Throught hole components insertion
3...IC pre-programming
4. Function verfication and burn in testing
5...Complete Unit assembly ( which including plastics, metal box, Coil, cable inside etc)
6. Enviromental Coating
7. Engineering including end of life components, obsolete component replace and design support for circuit, metal and plastic enclosure
8. Packing design
We are committed to improving our product quality constantly. Our operation is ISO 9001: 2000-certified, and the products deliveryed from us shall be full quality checked, striving to 100% customer's satisfaction is our long term mission.
To work with a reliable EMS provider with high mixed, low volume order, contact us today.
