High quality Multi-band radio(HT-777)
Product details:
Wave band:
AM:530-1710KHZ
FM:88-108MHZ
SW:4-9MHZ
9-14MHZ
14-19MHZ
19-26MHZ
WB:161.5-163.5MHZ
Packing:
Prdocut Size:
L164*D70*H138(mm)
Carton and quantity:30pcs/box
37.5x36.5x44.6cm
Box size:17.3x7x14.2cm
G.W:15.2kgs
N.W:14.4kgs
22800 units / GP
27600 units / GP
12000 units / GP
Function:
1.Charging method: A solar charger B: Dynamo C: External DC charging.
2.With 8 2 * 5 * 7mm lamp.
3.Available external headset to listen to radio.
4.32 built-in magnetic speaker.
5.Built-in rechargeable battery.
6.With battery detection function.
7.The IC Model: CD1691GB.
8.There 4.5V battery holder, the 5th battery * 3PCS.
Technical Parameters |
| 1.Solar panel size 100 * 28 * 3.2mm parameters 5V25mA (polysilicon) 12 hours in bright sun, the battery can be filled 3.6V/300mA |
| 2.Hand 1 minute / 150 lap segment audible FM radio 20 minutes, the volume is located 1/3. Dynamo 2 hours and 30 minutes, can be filled with 3.6V/300mA battery. |
| 3.Charging motor parameters: DC10.8V, rated current greater than 430mA, 10 ohms load. |
| 4.LED parameters: 2 * 5 * 7mm white hair Bai Chaoliang 10000-12000mcd |
| 5.Speaker parameters: Φ57mm32 magnetic 0.5W8Ω |
| 6.Adapter parameters: output DC voltage 6V/500mA |
| 7.Full segment FM radio built-in battery audible three hours, the volume is located 1/3. Filled with built-in battery LED lamps can be lit one hour 30 minutes. |
| 8.Can be equipped with a larger capacity rechargeable battery, but the price change. |
| 9.With 8 2 * 5 * 7mm lamp |
Welcome to you visit to our factory and samples any time.
Looking forward to you further inquiry and contact me
Dongguan Chashan Hai Tong Plastics Electrical Factory is a manufacturer specializes in designs & development, mold making, manufacturing and marketing.
Products mainly are energy saving & environmental items, they are solar dynamo radio, hand crank flashlight w/radio, and multi-function solar cell phone charger. They are suitable for household, traveling, entertainment and other outdoor activities.
The factory established in 2000. Its products mainly export to overseas such as North America, Europe, and Southeast Asia countries. The products conform to the standards of FCC, CE, RoHS, etc. Especially, we have obtained patents for the home market.
With high quality, reasonable pricing, abundant experience, excellent talent as well as high efficient, we are able to design and develop similar and correlative products for clients.
All of valued clients are welcome to work together with us to develop market and win multilateral interests!
