LED Panel Light

Product Specifications

Prod Model:	BE-PL-12W
Markets:	North America,Eastern Europe,Mid East,Western Europe
100% Wattage:	12W
LED Chips:	SMD2835
Cct:	3000k 7000k
Driver:	Isolation
Light Source:	LED
Emitting Color:	White
Dimmable:	Without Dimmable
Appearance:	Round
Type:	Ceiling
Base Material:	Metal
Certification:	RoHS
Voltage:	85V-265V
Housing Material:	Aluminum
Beam Angle:	120

Product Description

LED panel lamp 12W

Item code	RPL03	RPL06	RPL09	RPL12	RPL15	RPL18
Description	3W	6W	9W	12W	15W	18W
Size	80mm	120mm	150mm	170mm	200mm	225mm
Cutout	∮68	∮105	∮130	∮150	∮180	∮205
CRI	70	70	70	70	70	70
Lumen	210	420	630	840	1050	1260
Led chip	SMD2835
color temp.	ww,pw,cw
Housing	Aluminum+PC
Covering	frosted
Input voltage	AC86-265V
Beam angle	120
Working temp.	-25-65ºC
Lifespan	>30000hrs
Warranty	2 years

Quick Detail:
1.Designed to fit within a standard 600mm suspended ceiling frame,
2.These LED panels are ideally suited to commercial and retail environments.
3. Four concealed edge lighting LED strips and a specially designed diffuser ensure uniform illumination.
4.RGB model features fully programmable colour changing via the wall mounted.
