Shenzhen Myled Optech Co., Ltd. >> LED Panel Screen, LED Panel Display

LED Panel Screen, LED Panel Display

Name: LED Panel Screen, LED Panel Display
Brand: china-manufacturer-directory.com
SKU: 697287652
Availability: InStock
Rating: 4.6 (45 reviews)

Supplier:	Shenzhen Myled Optech Co., Ltd.
Price:	US $ 1-960/Piece
Min Order:	5/Square Meter
Quantity::
Trade Terms:	FOB,CIF,EXW

Product Specifications

Prod Model:	P6, P10, P12
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Outdoor:	IP65
Display Type:	LED Video Display
Tube Chip Color:	Full Color
IP Rating:	IP65
Pixel Configuration:	1R, 1G, 1B
Certification:	ETL
Pixel Pitch:	20mm
Display Function:	Video Display
Application:	Advertising
Scanning Mode:	Static Scan
Average Power Consumption:	220W / m²
Pixel Density:	2500

Product Description

The most cost effective LED display for outdoor application, being introduced to the market for more than 10 years.
We have to say, for outdoor advertising, P20 & P16, are the most reliable products since ever!

Main Parameter
Category	Parameter
Pixel Pitch	20mm
Optimum Viewing Distance	20-50m
Density of Pixel	2500pixels/
Brightness	≥6500nite	≥7000nite
Module Resolution	16*16
LED Encapsulation	DIP346 2R1G1B	DIP346 1R1G1B
Driving Method	Virtual Static	Real Static
Optimum Viewing Angle	H: 110°V:50°
Module Size	32032027.7(mm)	32032033.4(mm)
Module Power	44w	50w
Module Weight	1100g	1200g
Cabinet Size	1280960178(mm)	1280960183(mm)
Cabinet Resolution	64*48
Cabinet Power	1320w	750w
Cabinet Weight	59kg	59kg
IP Rating	Front/Rear:IP65/IP43
Refresh Rate	1000-4000Hz( Different according to the different Driving IC )
Luminance Consumption	Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature25ºC.
MTBF	>5000hours
Defective Dot Rate	<0.0001
Life Span	>100000hours
Working Voltage	110-240 AC±10% 50-60Hz
Working Temperature/Humidity	-30ºC - +50ºC/10-90%RH
Storage Temperature/Humidity	-40ºC - +60ºC/10- 90%RH
Input Signal	RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc
Connector	CAT5 Cable(Length≤1430m),Optical link( Length≤20km,Optional)
Note: The above parameter is just for reference. Changes can be made according to customers' requirements

Located in Baoan District, Shenzhen Myled Optech is an professional LED display manufacturer which is dedicated to LED display R&D; Production, sales, marketing and one stop solution for customers mainland and international. Myled provides consulting, installation, training and sales services for customers. We always regard customers as the company life line.

Shenzhen Myled Optech focus on indoor and outdoor full color LED display, LED curtain display, mesh, indoor and outdoor single and bicolor LED display manufacturing. We have established business relationship with customers in South America, Euro, and Asia etc. And win a good reputation among customers all over the world. And we provide full solution for Government, Telecom, Hotel, airport, bus station, stadium, and cinema and financial center, etc. Over the past years, we have finished some important LED display project for South American and China Mainland.

Quality is the most important theme for Myled and welcome to contact, and visit our company.

We hold the truth that better quality, better price and better sales services are our company culture.
