Level Meter

Name: Level Meter
Brand: China-Manufacturer-Directory.com
SKU: 669965802
Availability: InStock
Rating: 4.8 (126 reviews)

Supplier:	Dalian Teren Industry Instruments Import and Export Co., Ltd.
Price:	Negotiable
Min Order:	1
Quantity::

Product Specifications

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

Max-range 30m 2-wire series in liquids
Max-range 40m 4-wire series in liquids
Min resolution 1mm
LCD/LED big display
Intelligent signal processing technology
Simple configuration parameters, without waiting for emptying containers
Patent transducer structure. There is no request for the length of flange connection tube.
Rot-proof plastic crust protect grade IP67, and many crusts to be selected
HLU series with a dual-level relay
Flexible setup
DC/AC power supply, HLU series can be powered by AC

Measuring range	HLN4: 0-4m (in liquids); blacking distance: 20cm
	HLN6: 0-6m (in liquids), 0-2m (in solids); blacking distance: 25cm
	HLN8: 0-8m (in liquids), 0-4m (in solids ); blacking distance: 30cm
	HLN10: 0-10m (in liquids), 0-6m (in solids); blacking distance: 35cm
	HLN15: 0-15m (in liquids), 0-8m (in solids); blacking distance: 60cm
	HLN20: 0-20m (in liquids), 0-10m (in solids); blacking distance: 80cm
	HLN30: 0-30m (in liquids), 0-15m (in solids); blacking distance: 120cm
Accuracy	0.2% of full span (in air)
Output current	4-20mA
Power supply	DC24V(± 20%) ≥ 30mA
Output load	0-500 Ω
Output resolution ratio	0.03% of full span
Parameter set up	3 induction buttons
Temperature range	-40c ~80c
Temperature compensation	Automatic in the whole range
Pressure range	± 0.1MP (press definitely)
Beam angle	8 ° (3db)
Display	4 digit LCD (the height is 15mm)
Protect grade	IP67
Materials	The host: ABS\metal The probe: PVC\PTFE
