Light Flexible Soft LED Curtain Display for Rental Indoor

Name: Light Flexible Soft LED Curtain Display for Rental Indoor
Brand: china-manufacturer-directory.com
SKU: 736591225
Availability: InStock
Rating: 4.9 (149 reviews)

Supplier:	Shenzhen Vteam Co., Ltd.
Price:	US $ 540-1235piece
Min Order:	1piece
Quantity::
Trade Terms:	FOB,EXW

Product Specifications

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Pixel Configuration:	RGB3in1 SMD2121/3528
Panel Size:	500X1000X65mm
Refresh Rate:	>1920Hz
Gray Scale:	>14 Bits
Protection Level:	IP43
Power Supply:	AC 110-220V,50/60Hz
Working Environment:	Temperature-10-+50 Degree,Humidity 10-90%Rh
Life Time:	>50,000 Hours(>70% Luminous Output)
Certificate:	CE,RoHS
Export Markets:	Global
Tube Chip Color:	Full Color
Display Function:	Video Display
Application:	Shopping Guide
Pixel Configuration:	1R,1G,1B
IP Rating:	IP43
Certification:	RoHS
System Operating Platform:	WIN XP
Scanning Mode:	1/9scan
Pixel Pitch:	3.9/4.8/5.2/6.9mm
Pixel Density:	20736-65536 Dots/M²

Product Description

Product Description An Series(indoor)Overview: An Series (indoor) is the light-weight and super-thin led display screens, which are very popular for video rental business and large square applications. Jointed correctly, easy to install and dismount. Simple structures are the main features of the screens. The unit size of the screen is 500mm*1000mm*65mm, while the weight is only 13kg/panel. An Series (indoor) are popular to install on entertainment areas, such as TV stages and clubs. The video performances of the An Series screens are brilliant, pretty clear, and real. An Series (indoor)is the best choice for creative designing company to achieve large square video show. Product Features: 1. Light-weight. Convenient in transporting and installing saving labor cost, suitable for flow shows. 2. Nice appearance and simple structure. 3. Jointed precisely, being installed &dismounted by one person without tool. 4. Humanized operating interface with breakdown indicator lights, easy to maintain. 5. High debugging brightness and no damage for nice image.

Item	An3.9	An4.8	An5.2	An6.9
Pixel Pitch	3.9mm	4.8mm	5.2mm	6.9mm
LED type	SMD2121	SMD3528	SMD3528	SMD3528
Pixel matrix per panel	128*256	104*208	96*192	72*144
Pixel density/sqm	65536	43264	36884	20736
Brightness	900 Nit	1000 Nit	1300 Nit	1300 Nit
Driving Mode	1/16 scan	1/16 scan	1/16 scan	1/9 scan
View distance	≥ 3m	≥ 4m	≥ 5m	≥ 6m
Weight	13kg	13kg	10kg	10kg
Max. Power	200W/panel	250W/panel	120W/panel	120W/panel
Ave. Power	100W/ panel	130W/ panel	60W/ panel	60W/ panel
Panel Size	500mm x 1000mm x 65mm
LED Configuration	RGB 3in1
LED Lamp/Chip	Silar or Epistar
Viewing Angel	140° (H)/120° (V)
Gray Scale	≥ 14bit
Refresh rate	≥ 1920Hz
Color temperature	8000K ± 500(can be customized)
Colors Space	687 billion
Waterproof rate	IP43
Application	Indoor, rental& fixed
Input Signal	DVI, VGA, HD-SDI, S-video, Composite, YUV, etc
Input Voltage	AC 220V± 10%, 50/60Hz
Power Supply	Meanwell or G-energy with UL certificate
Display Media	Video, graphic, animation, signage, cartoon, text, etc
Control System	YDEA(showbox), Nova, Linsn, PC based dynamic capture & mapping
System Operating Platform	WINDOW98/2000/XP/7/8
Working Environment	Temperature: -10º C~+50º C, humidity: 10-90%RH
