Product Specifications
| Prod Model: |
TL-WS |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: |
Tailong Construction |
| Original Place: |
Qingdao |
| Dimensions: |
H,C,Z Steel |
| Size: |
Any Size Is Available |
| Crane Beam: |
5t,10t,15t |
| Grade: |
Q235/Q345 |
| Roof And Wall Panel: |
EPS, PU ,Rock Wool |
| Window: |
Plastic or Aluminum Steel Window |
| Material: |
Steel Structure |
| Usage: |
Workshop |
| Certification: |
CE |
| Customized: |
Customized |
Product Description
1. Strong steel structure frame is fastness, wind proof, snow proof, earthquake resistant.
2. Plasticity steel as steel warehouse materials is easy to design. So the warehouse is large space, light weight.
3color sandwich panel and color corrugated steel sheet as maintenance system is heat insulation, good appearance, waterproof, sound proof.
4Bolted connection steel workshop is easy to install and disassemble.
5. Cold bend steel gutter and downspout is good for drainage system.
The detail information is as follows:
| No. | Sort | Name | Specification |
| 1 | Specification | length | No limited |
| 2 | Width | Less than 11m |
| 3 | Wall height | 2600mm/2800mm |
| 4 | Clear height | 2600mm/2800mm |
| 5 | Roof slope | 15° |
| 6 | Standard accessory | Wall board | 75mm thickness double color-steel sandwich panel with polystyrene foam inside. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.546w/ m².k. |
| 7 | False ceiling | 75mm thickness double color-steel sandwich panel with polystyrene foam inside. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.546w/ m².k. |
| 8 | Roof board | color steel corrugated sheet, 0.5mm thickness |
| 9 | Outside door | Security door, single door with dimensions of 900*2100mm, furnished with a handle lock with 3keys. Doorframe is made of 1.2mm steel, and door is made of 0.7 mm steel, 90mm thick rock wool insulation foam. |
| 10 | Inside door | SIP, single door with dimensions of 750*2000mm, furnished with a cylinder lock with 3keys. Doorframe is made of aluminum, 50mm thick EPS insulation foam. |
| 11 | Window(W-1) | PVC, white color, with dimensions of 1200*1200mm, glazed with glass in a thickness of 5mm, two bay fixed, and two bay sliding, supplied with fly screen. |
| 12 | Window(W-2) | PVC, white color, with dimensions 500*500mm, glazed with glass in a thickness of 5mm, casement opening, supplied with fly screen. |
| 13 | Channel | Galvanized Steel Plain Sheet press moulding Material: Q235. Painted |
| 14 | Post | Square steel tube Material: Q235. Painted |
| 15 | Purline | Square steel tube Material: Q235. Painted |
| 16 | Roof truss | Square steel tube Material: Q235. Painted |
| 17 | Decoration and connection | color steel sheet, 0.35mm thickness |
| 18 | Option | Decorative floor | PVC, laminated or ceramic tile |
| 19 | Drainage system | Provided plan, design and construction |
| 20 | Electric system | Provided plan, design and construction |
| 21 | Technical parameter | Bearing load | 30kg/m2 |
| 22 | Wind pressure: | 0.45KN/M2 |
| 23 | Fire proof | B2 grade |
| 24 | Resistant temperature | -20 ºC to 50ºC |
Advantages:
# Environment friendly: All the materials of steel warehouse is made of steel, which can be reused many times.
# Good appearance: Warehouse with color steel sheet wall panel and roof panel is beautiful and tidiness.
# Quality: Steel structure warehouses with steel structure frame and colorful steel sheet panel is very fastness.
# Good drainage system with cold bend steel sheet gutter and pvc downpipe
# Connection: All the steel materials were connected with high strength bolts, shearing bolts, bracket bolts etc is easy to install and dismantle.
# Short delivery time. All the materials load in containers, ship abroad.
# Short production time: The warehouse with flexible design was devided into a number of steel structure parts, be manufactured by skilled workers in advanced machines.
# Installation: If needed, our engineers will provide technical guidance onsite.
Why us?
The ASTC Advantage
Competitive Prices Our production capacity (approximately 300000 metric tons annually) together with effective and economic engineering and manufacturing methods enable us to offer the most competitive prices in the industry.
Fast Quotations
Quotations for simple buildings can be submitted quickly due to vast experience of our staff and the advanced software we use.
Fast Delivery
We are able to design, detail, fabricate and supply simple buildings in approximately 8 weeks.
Most of our buildings are delivered and erected within 10weeks (this relies on various factors such as stock position, weather etc).
Site Supervision
A site supervisor is always present at site to ensure that work is being carried out satisfactorily.
Any problems that arise are quickly dealt with to minimise any delays.
Safety on site is also made a priority.
Exports & International Sites
Our projects and products have been used in many countries and regions, such as: Australia, yemen, Mongolia, Angola, South Africa, India, Bangladesh, Singapore, Sudan, etc
Vast Experience
Most of our staff have been with us for over 10 years, some even 20 years.
High Quality
Our product design, the manufacture is in line with SGS or BV inspection standards, can accept the whole process of SGS or BV inspection.
We have also designed to the most stringent ISO standards successfully.
We have an in-house Quality Control department that ensures that our workmanship is of good quality.
After Sales
The Project Coordinator responsible for your job will be in constant contact with you to make sure that your entire project is executed from start to finish.
Our view is to develop a long-term relationship with our clients, many of which are already lifetime partners.
Prestige
Steel Structures Ltd is one of the most reputable, professionally run businesses in the country
the following question we need to know before making the price.
| 1 | Location (where will be built?) | _____country, area |
| 2 | Size: length*width*height | _____mm*_____mm*_____mm |
| 3 | wind load (max. wind speed) | _____kn/m2, _____km/h, _____m/s |
| 4 | snow load (max. snow height) | _____kn/m2, _____mm |
| 5 | anti-earthquake | _____level |
| 6 | brickwall needed or not | If yes, 1.2m high or 1.5m high |
| 7 | thermal insulation | If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; . if not, the metal steel sheets will be ok. The cost of the latter will be much
lower than that of the former |
| 8 | door quantity & size | _____units, _____(width)mm*_____(height)mm |
| 9 | window quanity & size | _____units, _____(width)mm*_____(height)mm |
| 10 | crane needed or not | If yes, _____units, max. lifting weight____tons; max. lifting height _____m
|
Qingdao TaiLong Steel Structure Co, . Ltd was founded in June, 2003 and is located in Qingdao, enjoying convenient transportation and beautiful environment. We have a general investment of 70 million yuan and a plant area of more than 81 thousand square meters. Qingdao TaiLong Steel Structure Co, . Ltd has abundant financial resources and advanced equipment with 6 production lines. We have been in steel structure lines for 13 years and are specialized in producing all kinds of steel structure workshop, warehouse, building, prefab house, container house and villa. We are famous for superior quality, competitive prices, first-class craftworks, safe package, and prompt delivery. Therefore, we can fully satisfy your demands and have a large customer base. As a supplier, we have excellent teams who focus on product development & design, quality control & inspection and company running. In order to supply the best products and services, we have built a modern quality management system which is in strict accordance with international standards. Besides, because of large overseas markets, most of our products have got I S O 9 0 0 1 certificates. If you have any new ideas or concepts for the products, please contact us. We are glad to work together with you and finally bring you the satisfied products.
