Product Specifications
| Prod Model: |
lOkV SC(ZB)10 Series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Instrument |
| Phase: |
Three |
| Coil: |
Core-type Transformer |
| Cooling Method: |
Dry-type Transformer |
| Winding Type: |
Multi-winding Transformer |
Product Description
Basic info.:
Certification:ISO9001
Export Markets:Global
Packaging: standard package or cilent's requirment
Brand name: L&R or as per clients' requirements
1. Epoxy resin winding2. Integral casting3. Fire-proof4. Fine adaptability5. Exemption from maintenance 6. Low noiseSpecifications: 1. Voltage level: 6~35kV2. Capacity: 30~20000kV3. Regulation mode and tapping range: ± 2x2.5% (or ± 5%) none excitation regulation, ± 4X2.5% on-load regulation4. Nominal frequency: 50Hz5. Phase: Three-phase6. Label of coupling group: Yyno; Dyn11; YNd11 (or according to the customer's requirements)7. Short-circuit impedance: Standard impedance (can also be done according to requirement)8. Working environment: Altitude less than 1000 meters; Environment temperature lower than 40 C. (if the working surrounding exceeds these limits, special design and manufacturing process should be involved according to related standards)9. Heat resisting level: The upper limit of temperature is 155C, and the limit of temperature rise is 100k10. Cooling mode: Natural air cooling (AN), forced air cooling (AF)11. Insulation level: A. 6kV-type transformer: Work -frequency withstand voltage is 25kV; Impulse withstand voltage is 60kVB. 10kV-type transformer: Work -frequency withstand voltage is 35kV; Impulse withstand voltage is 75kVC. 20kV-type transformer: Work -frequency withstand voltage is 50kV; Impulse withstand voltage is 125kVD. 35kV-type transformer: Work -frequency withstand voltage is 70kV; Impulse withstand voltage is 170kV
Zhejiang Laurence Power Equipment Co, . Ltd. Is Located at Weishiyi Road, Economic Zone Yueqing Wenzhou City Zhejiang P. R. China which is specialized in producing Electric power fitting, Guy grip, make off, Dead end Clamp, P. G. Clamp, Surge arrester, Dropout fuse isolator, Varistor etc. And have been supplying various products to overseas customers for the electrical engineering industry, including Zinc Oxide Varistors, Arresters, insulators, Fuse Cutouts, Transformers, Line hardware and so on.
High quality and favorable price. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
Our products have being service in more than 20 countries power system.
We just focus on ELECTRIC POWER, and service the WORLD POWER.
