Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Lifetime: |
>8000hrs |
| Delivery Time: |
10-20day Depending on The |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Material: |
Element Semiconductor |
| Type: |
P-type Semiconductor |
| Package: |
Customized |
Product Description
1. Wavelength 635 nm, 650nm, 670nm, 780nm
2. L D Power 5 ~ 30mw (635nm), 5 ~ 70mw (650nm)
3. Operating Current 25 ~ 150 mA
INDUSTRIAL Laser diode modules are simple cost effective laser sources. They incorporate a semiconductor laser diode circuit, collimating lens and laser diode drive circuit, packaged in a rugged housing to provide continuous or pulsed laser output.
Application:
1. Industrial Instruments and Equipments
2. Wild Explore Instruments
3. Military Instruments and Equipments
4. Medical Instruments
Specifications
1, Wavelength 635 nm, 650nm, 670nm, 780nm
2, L D Power 5 ~ 30mw (635nm), 5 ~ 70mw (650nm)
3, Operating Current 25 ~ 150 mA
4, Operating Voltage 2.6 ~ 5.5 V DC
5, Operating Temp. -10° C ~ 50° C
6, Storage Temp. -40° C ~ 80° C
7, Case Material: Brass or Aluminum
8, Power Stability: > 90% (Voltage range 2.7 ~ 5.5 V DC )
> 85% (Temp. Range -10° C ~ 50° C)
9, Consistency ± 0.1 mw
10, Life time > 8000h
Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.
Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.
Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.
