Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certification: |
ISO9001 |
| Size: |
According to Your Requirements |
| Application: |
Network |
| Material: |
Copper |
| Interface Type: |
USB |
| Pin: |
4Pin |
| Feature: |
Waterproof |
| Power Cable Type: |
Three-pin |
| Shape: |
Round |
| Computer Cable Type: |
Power Line |
| Printer Cable Type: |
USB |
| Color: |
Black |
Product Description
Product Description
Standard Implemented:
The product conforms to Q/321084 KLA049-2004, Q/321084 KLA 052-2004,euual to the Bristish BS5306-86.
Application:
It applies to the computer, automatic and other correponding systems of power generation, smelting and petrochemistry.
Service Characteristics:
Rated voltage Uo/U:450/750V
Operating temperature Max:
For common types: ≤70ºC
For XLPE: ≤90ºC
For resistance to heating less than '105ºC': ≤105ºC
Bend radius Min:
For cable without armor: ≥6 times outer diam.
For cable with armor: ≥12 times outer diam.
No. | Types | Description | Place of use |
| 1 | DJYPV22 | PE insulated, pair-twisted Cu wire woven, divided screen,
PVC sheathed and steel tape armored computer control cable | Can be laid in indoor, tunnels and places being able to bear large outer mechanical force. |
| 2 | DJYPVP22 | PE insulated, pair-twisted Cu wire woven, divided and total screen,
PVC sheathed and steel tape armored computer control cable |
| 3 | DJYVP22 | PE insulated, pair-twisted Cu wire woven, total screen,
PVC sheathed and steel tape armored computer control cable |
| 4 | DJYP2V22 | PE insulated, pair-twisted Cu tape divided screen,
PVC sheathed and steel tape armored computer control cable |
| 5 | DJYP2VP2-22 | PE insulated, pair-twisted Cu tape divided and total screen,
PVC sheathed and steel tape armored computer control cable |
| 6 | DJYVP2-22 | PE insulated, pair-twisted Cu tape total screen,
PVC sheathed and steel tape armored computer control cable |
| 7 | DJYP3V22 | PE insulated, pair-twisted Al/plastics combined tape, divided screen,
PVC sheathed and steel tape armored computer control cable |
| 8 | DJYP3VP3-22 | PE insulated, pair-twisted Al/plastics combined tape, divided and total screen,
PVC sheathed and steel tape armored computer control cable |
| 9 | DJYVP3-22 | PE insulated, pair-twisted Al/plastics combined tape, total screen,
PVC sheathed and steel tape armored computer control cable
|
The company is set Branch, engineering, trade and an integrated enterprise, the main production: Wire and cable, instrument of the three categories of over 500 varieties of more than 2000 specifications. The company provides the following products for your selection and welcomed the use of its main products are: WR series thermocouple, WZ series of thermal resistance, bimetal thermometers, gauges, intelligent digital regulator controllers, temperature converters, display and power cable special cables, control cables, electrical wire and cable equipment communication cables, thermocouple wire compensation, compensation cable and high-temperature fluorine plastic compensation wire, cable, silicone rubber control cables, overhead cables, ACSR and aluminum cables, etc...
The company attaches great importance to science and technology development and technological progress, in December 2000 introduction of a special cable production line, self-regulating heating cable series is currently the most favored by the majority of users of high-tech products. The Company and the National Institute of more than 10 projects to establish a cooperative relationship, sales network throughout the country.
We will adhere to the "technology works, good faith, " the purpose and dedication to providing quality products and excellent service. Welcome patrons, the inquiry.
