Product Specifications
| Prod Model: |
XFS |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Automation: |
Automatic |
| Screw: |
Double-Screw |
| Certification: |
CE |
| Computerized: |
Non-Computerized |
Product Description
Features:
Highly finished cutting tools made of imported special tool steel,the clearance of which are adjustable.The cutting tools are durable and can be ground repeatedly.
Recovery can be completed within 30 seconds.
There is no need to grind collectively and therefore the equipment can always be kept clean and dry.Low speed and with sound isolation,so the noise is very little.
Equipped with double spacing switch and automatic sudden stop arrangement.It can efficiently guarantee the safety of operators.
Inlet hopper is designed specially with antirust device which can efficiently prevent from leak and pollution in the grinding process.
Outlet hopper perfectly designed makes it quite convenient for operators to clean the machine.
|
Model |
XFS180-A |
XFS180-B |
XFS230 |
|
Power |
2.2kw |
2.2kw |
3kw |
|
Quantity of rotating blades |
9 |
9 |
9 |
|
Quantity of fixed blades |
2 |
2 |
2 |
|
Screen size |
Φ6-Φ8mm |
Φ6-Φ8mm |
Φ8mm |
|
Weight |
100kg |
100kg |
180kg |
|
Max.breaking capacity |
120kg/hr |
120kg/hr |
200kg/hr |
|
Size of feeding inlet |
180×136mm |
180×160mm |
230×160mm |
|
External size |
850×500×1000 mm |
850×720×1250mm |
960×960×1250mm |
