Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
9*1.89*2.26m |
| Weight: |
6.5tons |
| Colour: |
Blue Green Orange |
| Material: |
Aluminium |
| No.of Welding Heads: |
22 Points |
| Air Press: |
0.6~0.9mpa |
| Daily Output: |
8000sqm |
| Type: |
Plastic Welders |
| Current: |
Alternating Current |
Product Description
Machine welding grid introduction
My company manufacture geogrid production line equipment is determined by more than one combination of ultrasonic plastic welding machine adopts imported PLC control has the following advanced features:
1, touch-screen display and parameter setting, imported piezoelectric ceramic transducer, the output strength and stability.
2, color display touch-screen control panel.
3, all-Chinese menu, with multi-language you set, easy to use.
4, levels of adjustable mold design, mold fast and easy adjustment.
5, the new power amplifier circuit, power is more robust, more durable transducers,
6, frequency automatic tracking, a variety of parameter settings. High degree of automation in the domestic production of similar products in the leading position.
Welcome to our factory to check machine welding grid!
Geocell welding mold-digit |
HJM-11 |
HJM-14 |
HJM-15 |
HJM-18 |
HJM-22 |
No.of welding heads |
11 unit |
14 unit |
15 unit |
18 unit |
22 unit |
Max. Power |
28.6KW |
36.4KW |
36.6KW |
46.8KW |
57.2KW |
Ultrasonic Vibrating Power |
16.5KW |
21KW |
23KW |
27KW |
33KW |
SIZE OF THE EQUIPMENT (L*W*H)(M |
6.5*1.89*2.26 |
7*1.89*2.26 |
8*1.89*2.26 |
8*1.89*2.26 |
9*1.89*2.26 |
WEIGHTNESS |
5TONS |
5.5TONGS |
5.8TONS |
6TONS |
6.5TONS |
POWER |
AC380V N 50-60HZ |
AIR PRESS |
0.6~0.9MPa |
AIR COMPESSOR DISPLACEMENT |
≥2.5~3.0/min |
VOLOUM OF AIR COMPRESSOR AIR STORAGE |
1.5~2.0M3 |
2.5~3.0M3 |
WELDING DISTANCE SCOPE |
220-1000mm |
GEOCELL STRIP WIDTH |
220MM MAX (ADJUSTABLE ACCORDING TO THE SIZE OF WELDING HEAD) |
DAILY OUTPUT (REF) |
4500SQM |
4800SQM |
5000SQM |
5200SQM |
8000SQM |
|
Shanghai Hongjin Ultrasonic Electronic Equipment Factory, is a specialized research and development, production, sales ultrasonic equipment and electronic products in one company. Has advanced ultrasonic testing equipment and a number of specialized ultrasound industry for over 10 years of senior R & D personnel.
We are professionals dedicated to a variety of high-precision ultrasonic equipment research and development, comprehensive development of a variety of ultrasonic welding technology and non-standard equipment. Product quality, reliable, high-tech, the main parts are from Europe, the United States, Japan and other regional and national import, I pioneered the improvement of ultrasound technology, and the first use of digital circuit design, the first microcomputer technology into the ultrasound industry, operation using high-precision numerical control means, in similar products with a strong competitive edge.
The company with a strong product development capability and perfect quality management system and after-sales service system, many customers at home and abroad to provide well-made, superior performance of production equipment and services.
The company in pursuit of quality, sincere service for the purpose; To customer satisfaction as the goal; To oversee the development of the industry ultrasonic responsibility will be a number of international advanced technology into the ultrasound industry. We will establish are unique to the industry norms, and aspire to be a model for ultrasonic industry forever.
