Made in China R25/T38/T45thread Cross Carbide Bit

Product Specifications

Prod Model:	R25/T38/T45
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Cross Bit

Product Description

R25/T38/T45Thread Cross Carbide Bit

Description

Our cross bits diameters are from38mmto127mm, and different type are available, like R22,R25,R32, R38, T38,T45,T51,ST58, ST68,etc

Advantage

1. Excellent drilling penetration
2. Used in very hard or hardest rock formation
3. Adequate for various construction conditions
4. Strong corrosion resistance

Application

1.The cross bit is suitable for digging of very hard rock formation, hard formation and crack- grown formation.
2.All cross bits have to be reground at regular intervals to crush rock efficiently.
3.We choose different material and size for the cross bits in order to adapt the different rock formations and working conditions.

Technical Parameter

H25


Cross Tye Bits H25	Diameter		Button(mm)	Flushing Holes		Part No.
	mm	inch	LengthxWidthxHeight	Side	Front
	35	1 3/8"	13*8*12	4	1	GLS35-H25
	38	1 1/2"	14*8*12	4	1	GLS38-H25
	41	1 21/32"	15*8*12	4	1	GLS41-H25
	45	1 49/64"	17*8*12	4	1	GLS45-H25
	48	1 57/64"	17*8*14	4	1	GLS48-H25
	51	2"	19*10*16	4	1	GLS51-H25
	57	2 1/4"	22*10*16	4	1	GLS57-H25
	64	1 33/64"	24*10*16	4	1	GLS64-H25
	76	3"	29*12*20	4	1	GLS76-H25



R25/R28


Cross Tye Bits R25(1") R28(1 1/8")	Diameter		Button(mm)	Thread	Part No.
	mm	inch	Weight*Height
	35	1 3/8"	14*8	R25	GLS35-R25
	38	1 1/2"	14*8	R25	GLS38-R25
	41	1 5/8"	14*8	R25	GLS41-R25
	43	1 11/16"	14*8	R25	GLS45-R25
	38	1 1/2"	14*8	R28	GLS38-R28
	43	1 11/16"	14*8	R28	GLS43-R28
	45	1 3/4"	14*8	R28	GLS45-R28



R32


Cross Tye Bits R25(1") R28(1 1/8")	Diameter		Button(mm)	Thread	Part No.
	mm	inch	Weight*Height
	45	1 3/4"	16*10	R32	GLS45-R32
	48	1 7/8"	16*10	R32	GLS48-R32
	51	2"	16*10	R32	GLS51-R32
	57	2 1/4"	16*10	R32	GLS57-R32
	64	2 1/2"	16*10	R32	GLS64-R32
	76	3"	16*10	R32	GLS76-R32


Taper Cross Bit


Taper Cross Bit	Bit Diameter		Buttons	Taper	Water Holes	Part No.
	mm	in	Width*Height
	32	1 17/64"	6-8*12	7°	3	GL132-722
	34	1 11/32"	6-8*12	7°	3	GL134-722
	36	1 27/64"	6-8*12	7°	3	GL136-722
	38	1 1/2"	6-8*12	7°	3	GL138-722
	40	1 37/64"	6-8*12	7°	3	GL140-723
	42	1 21/32"	6-8*12	7°	3	GL142-723



Our Services
Delivery Time: Based on order quantity, normally it takes 30 days for production.Only 2 or 3 days if we have stock on your request size.
Quality Control: We have our professional QC and all the products will be strict inspection and testing for every order before shipping out.
After Services: Technical Support will be available in any time. We could provide the professional suggestion for you.
EX: 1.Select the right most suitable products.
       2. According to the rock types, choosing the face type, button tooth type.
       3. According to the different purpose,. choosing the different body type
