Product Specifications
| Prod Model: |
HPA-055 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certification: |
SGS |
| Method Type: |
Manual |
| Type: |
Electrostatic Spraying Equipment |
| Application: |
Wooden, Plastic, Glass & Metal Products |
Product Description
HPA-055 General Type Manual Electrostatic Liquid Spray Machine
Configuration: Spray gun *1 + HV generator *1 + paint pump*1 +HV generator holder*1
Technical Parameter
A). Electrostatic Generator
Input Power Voltage: AC200-240V/50-60Hz (Different countries, different standard)
Output Voltage: DC75V
Over-current Alarm: 20uA-80uA adjustable
Switch: High Pressure Safety Cut-out & Air-break
Working Temperature: 0~45ºC
Humidity: 20%-85%
Dimension: W200mm*H250mm*L150mm
Weight: 6kgs
B). Painting gun
Max. Output Voltage: DC60KV
Length of Gun Cable: 5m
Length of Paints Hose: 6m
Length of Air Tube: 6m
Paint Pressure: 0.3Mpa, Max.: 0.6Mpa
Air Pressure: 0.3Mpa-0.55Mpa, Max.: 0.6Mpa
We are the professional manufacturer which was established in 1991, specializing in electrostatic coating equipment.
Our machines are available in various configurations to suit a wide range of applications and suitable for mass production.
We undertake all kinds of lines: Aluminum, metal coating industry, paint curing oven works and so on.
We are making our efforts to pursue customer satisfaction based on technologies and reliability. Even at this moment, we are striving to be a top-ranking company leading the automatic electrostatic coating system field in Korea and China.
We are trying our best to recompense customers for their support by improving productivity of coating systems and related machines to meet the needs of customers. Not only are we striving for the sales increase, but we do devote ourselves to R & D for high-quality products, thereby being a partner of our customers to satisfy customers' requirements.
We truly seek after reliability for customers, providing high-quality products.
If you have any questions about our products, please do not hesitate to contact us.
Our efforts to accomplish our mottoes, 'Quick After-Sales Service', 'Development of New Technologies' and 'Management with Full Responsibility' will be continued.
