Product Specifications
| Prod Model: |
IC-M32 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Mid East,Eastern Asia,Western Europe |
| Frequency Range: |
VHF/UHF |
| Output Power: |
5W |
| Channel Number: |
50 |
| Ctcss: |
50 Groups |
| Talk Range: |
8km Max |
| Style: |
Handheld |
| Usage: |
Home, Commercial |
| Battery Type: |
Li-ion Battery |
Product Description
Marine Radio IC-M32
Working frequency range: 136-174MHz, 350-390MHz, 400-490MHz
50channels, keypad with night lighting aid
Input the necessary frequency directly by the digital keyboard, 6 function keys achieve various operation
50 groups CTCSS
Signal/channel scanning functions
High power output
Power saving
5W output power, 400mW audio output
In-built VOX function, hands-free talking
In-built CTCSS / DTMF functions
New and short design for antenna, better transmitting / receiving ability
Programmable through PC or radio itself, wireless copy
All trademarks and copyrights on this page are owned by their respective owners.
| General |
| Frequency Range | | Tx | 156.025-157.425 MHz | | Rx | 156.050-163.275 MHz |
| | Usable channels | USA, CAN, INT, WX channels | | Type of emission | 16K0G3E (FM) | Current drain
(at 7.5V DC) | | Tx | at 5W output | 1.5A typical | | Rx | at AF max. | 200mA typical | | | Stand-by | 20mA typica |
| | Operating temperature range | -20°C to +60°C;
-4°F to +140°F | | Antenna impedance | 50Ù (STUD) | | Dimensions (projections not included) | 61(W)x135(H)x41(D)mm;
213 /32(W)x55/16(H)x1 5/8(D)in | | Weight (approx.; with BP-224) | 360g; 12.7oz |
|
| Transmitter |
| Output power | 5W (High), 1W (Low) | | Modulation system | Variable reactance frequency modulation | | Max. freq. deviation | ±5kHz | | Frequency error | Less than ±10ppm | | Spurious emissions | Less than -68dBc | | Adj. channel power | More than 70dB | | Audio harmonic distortion | Less than 10% (at 60% mod. | | Residual modulation | More than 40dB |
|
| Receiver |
| Intermediate freq. | 1st 21.7MHz, 2nd 450kHz | | Sensitivity | 0.22ìV typical | | SQL sensitivity (at threshold) | Less than 0.35ìV | | Adjacent. Ch. selectivity | 70dB typical | | Spurious response | 70dB typical | | Intermodulation rejection | 70dB typical | | Hum and noise ratio | More than 40dB | | Audio output power | 0.35W typical at 10% distortion with a 8Ù load |
|
