Price: | US $ 95/Piece |
---|---|
Trade Terms: | FOB,CFR,CIF |
Min Order: | 1/Piece |
Pay Type: | L/C,T/T,D/P,Paypal,Western Union |
Prod Model: | PC |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Motor Power: | 0.25kw-4kw |
Input Speed: | 1400 Rpm or Other |
Speed Ratio: | 2.73 |
Output Torque: | 3.0n.M-500n.M |
Motor Coupling: | Flange |
Color: | Blue,Silver or Customised |
Quantity Control: | ISO 9001 |
Manufacturing Method: | Rolling Gear |
Toothed Portion Shape: | Double Helical Gear |
Type: | Circular Gear |
Material: | Aluminium |
Features
1.Compact mechanical structure, light weight, small volume&Good heat-dissipating
2.Smooth operation with lower noise or vibration
3.Easy mounting, free linking, high efficiency
4.Upto 96% transmission efficiency
5. PERFECT SUITABLE FOR IEC MOTOR AND GEAR REDUCER
Applications
Wide range of application,including light industry of food &beverage, Cement,
package,construction material,chemicals and etc.
Technical data:
Model | PC063 ,PC071,PC080,PC090 |
Single unit versions | IEC motor mounting |
Power | 0.25----4KW |
reduction ratio | 2.73 |
Output torque | 3.0---500N.M |
Gear material | 20CrMnTi with carburizing and quenching.The hardness of surface is 56-62HRC with carbonized layer 0.5-0.8mm |
After-sale service:
One year warranty,subject to proper operation and installation;free technical support all the time.
