Foshan Zhong Hao Xing Woodworking Machine Co., Ltd. >> Max Working Width 120mm Five Cutting Head Woodworking Machinery

Max Working Width 120mm Five Cutting Head Woodworking Machinery

Name: Max Working Width 120mm Five Cutting Head Woodworking Machinery
Brand: china-manufacturer-directory.com
SKU: 724837475
Availability: InStock
Rating: 4.7 (137 reviews)

Supplier:	Foshan Zhong Hao Xing Woodworking Machine Co., Ltd.
Price:	US $ 10500SET
Min Order:	1SET
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	ZHX-M512
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Max Working Width:	120mm
Certification:	SGS
Drivetrain:	Machine Drivertrain
Motor Power:	18.95kw
Working Depth:	8-100mm
Working Width:	15-120mm
Type:	Four-Side Moulder

Product Description

？Four-side moulder 1) Each principal axis adopts independent drive to electric motor,features stronger cutoff force. 2) Adusts for principal axis integrates at central of frontal side, features easy operation. 3)Galvanized workstation features superior abrasion resistance. 4)Equips with auxiliary unit alarming lack of material,it effectively improves smooth feed-in while lack of material. 5)Active roller below improves feeding efficiency. 6)Pneumatic pressing feeding roller section by section adjusts for pressing force,it favors for smooth feed-in of different thicknesses of timber. 7)Adopts central charging system,feetures convenience and promptness. 8)Equips with world-class electric element,features superior stability. 9)With fully sealed safety protective cover, this effectively avoids flying logging debris and noise blocked, and even acts as safety protection. 10)Double-deck working tables;it is easy for maintenance. 11)Pneumatic Pressing Feeding Roller Section By Section By Section Adjusts For Pressing Force, It Favors Forsmooth Feed-In Of Dfferent Thickness Of Timber.？？

MODEL:ZHX-M512
Technical Data:
ONE\Machine Parameter:
Working Thickness:	8-100mm
Working Width:	15-120mm
Operating Platform length:	1250mm
Feed Speed:	5-20m/min
Spindle Diameter:	ø40mm
Spindle Speed:	6000r/min
Gas Source Pressure:	0.6MPa
Two\Motor Power:
The Ist Bottom Spindle:	3kw/4HP
The Ist Top Spindle:	4kw/5.5HP
Right Side Spindle:	3kw/4HP
Left Side Spindle:	3kw/4HP
Second Top Spindle:	__
Second Bottom Spindle:	3kw/4HP
Feed Beam Rise&Fall:	0.55kw0.75HP
Feeding:	3kw/4HP
Total Motor Power:	18.95kw/24HP
Three\Knife Diameter:
Right Side Spindle:	ø125-ø160mm
Left Side Spindle:	ø125-ø160mm
The Ist Bottom Spindle:	ø125
The Ist Top Spindle:	ø125-ø160mm
The Second Top Spindle:	ø125-ø160mm
The Second Bottom Spindle:	ø125-ø160mm
Feed Diameter:	ø120mm
Dust Diameter:	ø125mm
Oversea Machien Dimensions(**)mm	300015501750mm
NET Weight(kg):	2200
Gross Weight(kg):	2280
