Supplier: | Zhejiang Nonarc Electric Co., Ltd. |
---|---|
Price: | US $ 0.75/Piece |
Min Order: | 100/Piece |
Quantity:: | |
Trade Terms: | FOB,CFR,CIF |
![]() |
Prod Model: | MB1-63 |
---|---|
Installation: | Insert |
Speed: | Normal Type Circuit Breaker |
Protection | Overload and short circuit | ||||
Standard conformity | IEC: 60898 | ||||
Type/Series | B | C | D# | ||
Rated current(In) | A | 6-63* | 6-63* | 6-63* | |
Rated voltage(ac)(Ue) | V | 240/415 | 240/415 | 240/415 | |
Rated frequency(f) | Hz | 50/60 | 50/60 | 50/60 | |
Nos. of poles(Execution) | 1P, 1P+N, 2P, 3P, 3P+N, 4P | ||||
Rated short circuit breaking capacity | kA | 6 | 6 | 6 | |
Utilization category | |||||
Magnetic release setting | (3-5)In | (5-10)In | (10-20)In | ||
Rated insulation voltage(Ui) | V | 660 | 660 | 660 | |
Rated impulse voltage(Uimp) | kV | 4 | 4 | 4 | |
Electrical/Mechanical Endurance(no. of operations) |
Less than 32A | 20000 | 20000 | 20000 | |
More than 32A | 10000 | 10000 | 10000 | ||
Ambient temperature | º C | -5 to +55 | -5 to +55 | -5 to +55 | |
Terminal capacity(max) | sq. mm | 25 | 25 | 25 | |
Protection class | IP20 | ||||
Installation postion | Vertical/Horizontal | ||||
Mounting | Clip on DIN rail(35mm*7.5mm) | ||||
Case & Cover | Moulded, flame retardant thermoplastic meterial |
