Product Specifications
| Prod Model: |
DLJX-JXXT |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand: |
Dolang |
| Type: |
Teaching Model |
| Usage: |
Training |
Product Description
Mechanical System Comprehensive Training System DLJX-JXXT
1, The main technical performance
The input power supply: Single-phase three-wire AC220V ± 10% 50Hz
2, The working environment: Temperature -10 ° C to 40 ° C Relative humidity ≤ 85% (25 ° C) Height ≤ 4000m
3. Dimensions: 1845mm X 690mm X 1770m
4. Security: Drain voltage, leakage current protection, security in line with national standards
2. Training project
Speed and torque measurement
Mechanical efficiency
Shaft and seat belt bearing
Shaft and flexible coupling
Flat belt installation and tensioning
Flat pulley installation and adjustment
Belt drive speed, torque, and the transmission ratio
Chain and sprocket installation and tension adjustment
Chain drive speed, torque, and the transmission ratio
Gear installation and adjustment, gear speed, torque and gear ratio, gear sets
V-belt and jagged edges of the belt, ribbed belt drives
Ordinary timing belt and high torque synchronous belt drive
Multi-row roller chains and tooth chain drive sprocket idler
Flange couplings, gear coupling, chain coupling and Grid Couplings, Universal coupling
Dial indicator use
With seat bearing lubrication, chain lubrication
Oblique spur gear
Worm gear
Gear box
Slide to bearings, deep groove ball bearings, angular contact ball bearing Roller, roller bearings
Bearing lubrication, gaskets, O-rings, lip seals, mechanical seals
One-way roller clutch
Torque limiter
Electromagnetic clutch
Electromagnetic brake
Ball screw, ball screw lead and the transmission ratio
The use of linear bearings
Use and vibration analysis adjustment of measured vibration meter
1) Electrical technology Know-how Training Set
2) Innovative E-skills&Technology Training Series
3) MCU Technology Training Series
4) Machine Tools Electrical Control Training Series
5) Machine Tools Electrical Control Training Series(Model-type)
6) CNC Machine Tools Maintainance Training Series(Model-type)
7) Building Automatic Training Series
8) PC Training Series
9) Innovative industrial Automatic Control Technology Training Series
10) Pnematic Training Series
11) Hydraulic Training Series
12) Sensor Training Series
13) Motor trainer
14) Mechatronic Training Series
15) MPS Training Series
16) FMS Training Series
17) Mechanical Training Series
18) Engrave Machine Series
19) Automotive training series
20) New engery training set
Packaging Detail:
1). Packaging for training kit: Plastic package + carton + plywood pallets
2). Packaging for training equipment: Plastic package + plywood pallet
Delivery Detail: 40 to 50 days after Received advanced payment.
After-Service And Training for Foreign User
Product Overview
This system is for colleges, vocational schools, vocational education and training institutions developed industrial maintenance training equipment, it s composited application according to mechanical teaching and typical mechanical structure in the industrial production, to enable students to master the mechanical transmission components selection, installation, maintenance and troubleshooting.
Industrial maintenance training bench can make the training project of mechanical transmission component installation, using, maintenance and troubleshooting training. This system enabling students to master and in-depth understanding the course theoretical knowledge and through practical ability to improve and analyze problems, problem-solving skills.
1) For our exported equipments, the Warranty is one year, within one year, if there is any problem for spare parts(except damage by man-made) We can supply and replace free of charge. And if after one year, we also supply the service. The difference is user need to pay it.
2) We dispatch our professional and experienced engineer to install equipments and make training for the end users.
Q1: What factors affect the price?
The quality of components: All the components we use are real industrial components which under EURO standard.
Technic: We pay much attention on the technics and details. Our products meet the requirement of Germany standard
Quantity: The price is up to the quantity of each item.
Q2: All equipments are designed by Dolang?
Yes. All our equipments are designed by ourselves.
The design department including: Electric research design department, Electrical research design department, Mechanical research and design department, Software research design department, Pilot test department and technical documents department.
Shandong Dolang Technology Equipment Co., Ltd. Was founded as a partner of Shandong university in 1998. Thanks for the customers, professional engineers and all our skilled workers, Dolang has been grown up to a professional and powerful global enterprise with 16 years dedicated experience on the didactic equipment. As a member of Worlddidac Association, our products are made under the requirement of ISO9001, ISO24001 and OHSMS28001.
We are professional on manufacturer electrical & electronic, PLC, fluid mechanical, hydraulic, pneumatic, process control, mechatronics, automation, CIM training and automobile training systems.
Besides the physical training system, Dolang provide solutions for customer such as system thinking, E-learning and so on.
Our products are involved in various education equipment industry fields. We serve in 100 universities and more than 300 vocational colleges in China. With self-operation export & import license, our products have being exported to France, Russia, Mongolia, Tunisia, Mexico, Brazil, Peru, Indonesia, Iraq, Cyprus, Vietnam, Kazakhstan etc.
