Membrane Contactor Match for Gwiec Contactor 10A to 630A Cj20 Type

Product Specifications

Prod Model:	CJ20-63A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Circuit Rating Voltage:	380~660V 80 Membrane Contactor
Circuit Rating Current:	9~620A
Suitable For Frequency:	50/60Hz
Membrane Contactor Standard:	IEC60947 Membrane Contactor
Membrane Contactor Auxiliary Contact:	2no+2nc/1no+1nc
Life Time(Mechanical):	2400~3600 Times
Life Time (Electrical):	1200~300 Times
Membrane Contactor Function:	Protect Over Load Phase Circuit
Match Fuse Type:	Rt16 Type
Material:	Copper and Anti Fire Plastic
Load:	Medium Power Relay
Protective Characteristics:	Open Relay
Theory:	Electromagnetic Relay
Size:	Miniature
Usage:	Car Relay, Household Appliances Relay, Communication Relay, Lathe Relay
Action Principle:	Electromagnetic Type

Product Description

membrane contactor match for GWIEC contactor 10a to 630A cj20 type   is suitable for the power system of AC 50Hz or 60Hz, rated working voltage up t0 660V or 1140V and rated working current up to 630A, used to make and break circuit frequently in a far distance, while, it can be combined with thermal relay or electronic protection equipment to form into an electromagnetic starter, to protect the circuit against possible overload  The products are in conformity with such standards IEC 60947-4-1.

membrane contactor match for GWIEC contactor 10a to 630A cj20 type  Main technical data

Type	Ui V	Ue V	lth  A	Period working left current				AC-3 Pe (kw)	Le under  uninterrupted  duty(le A)	Weight (kg)
				AC-1	AC-2	AC-3	AC-4
CJ20-10	690	220	10	10	-	10	10	2.2	10	0.353
		380						4
		660				5.2	5.2
CJ20-16	690	220	16	16	-	16	16	4.5	16	0.416
		380						7.5
		660				13	13	11
CJ20-25	690	220	32	32	-	25	25	5.5	32	0.67
		380						11
		660				14.5	14.5	13
CJ20-40	690	220	55	55	-	40	40	11	55	1.32
		380						22
		660				25	25
CJ20-63	690	220	80	80	634	63	63	18	80	2.9
		380						30
		660			40	40	40	35
CJ20-100	690	220	125	125	100	100	100	28	125	3
		380						50
		660			63	63	63
FJ20-160	690	220	200	200	160	160	160	48	200	5.5
		380						85
		660			100	100	100
CJ20-160/11	1140	1140			80	80	80
CJ20-250	690	220	315	315	250	250	250	80	315	10.5
		380						132
CJ20-250/06	690	660			200	200	160	190
CJ20-400	690	220	400	400	400	400	400	115	400	11.7
		380						200
		660			250	250	200	220
CJ20-630	690	220	630	630	630	630	500	175	630	21.5
		380						300
CJ20-630/06	690	660	400	400	400	400	320	350	400
CJ20-630-11	1140	1140						400

membrane contactor match for GWIEC contactor 10a to 630A cj20 type   advantage
1.20 years global leading profession manufacture of energy meter
2.Long life high reliability
3.It will match to thermal relay ,protect over load or lack phase circuit
4.Fast delivery : you will get the order when you need it
5.OEM is warmly welcome
 6.3 line assemble line ,each day will make more than 100000pcs
7.Convenient : 45 minutes to wenzhou airport
8.Rated current Max 150A within 380V   max 100A within  660V .

membrane contactor match for GWIEC contactor 10a to 630A cj20 type   function
1.saving power
2.No invoice
3.No temperature rise
4.Auxiliary contact without vibration
5.Long life, high reliability
6.Anti electromagnetic interference
7.Intelligent anti electricity dazzling

membrane contactor match for GWIEC contactor 10a to 630A cj20 type    Payment terms
1. 30% T/T advance , the balance against to the copy B/Lor LC at sigh
2. The other specific issues can negorate.
3. Pls confirm the details with us before do the prepayment.

membrane contactor match for GWIEC contactor 10a to 630A cj20 type   Packing information
1. Inside foam package ,outside strong paper package
2. 20pcs/per CTN
3. G/N.W: 16/15kg
4. We can packing as your required,good looking design

Why choose membrane contactor match for GWIEC contactor 10a to 630A cj20 type
1).ISO9001,SGS,Gold golden supplier
2) Monthly Production Capacity -- 100000 Pcs
3)All goods examined before delivery by 10 QC staff
4)Prompt Reply Within 12 Hours
5)8000 square meters work environment
