Product Specifications
| Prod Model: |
ZK various |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Ore Dressing, Magnesium Production Line |
| Model: |
Bf-0.37~Bf-24 |
| Volume (M3): |
0.37-24 |
| Capacity: |
0.2-24 (M3/Min) |
| Shipping Port: |
Qingdao,Shanghai |
| Installation: |
Under Our Engineer's Guide |
| After Sale Service: |
for The Whole Using Life |
| Experience: |
More Than 50 Years |
| Company Established: |
1956 |
| Spare Parts: |
We Offer |
Product Description
The BF flotation machine
Introduction of gold mining machinery:
Flotation machine is widely used for roughing, concentrating and reverse flotation of nonferrous metals that include copper, lead, zinc, nickel and molybdenum, ferrous metal and nonmetallic minerals.
The BF flotation machine impeller is composed of the closed double frustum, may produce the strong slurry under to circulate, its characteristic: (1) the suction intensity is big, the power loss is low. (2)each trough has the suction, attracts the thick liquid and the flotation process function, from becomes the flotation process return route, does not need any supporting facility, the level disposition, is advantageous for the flow change. (3) the slurry circulation is reasonable, can maximum limit reduce the coarse sand precipitation. (4) is equipped with the slurry surface automatic control and the electrically controlled installment, the adjustment is convenient.
Features of gold mining machinery:
1. Large air-absorption capacity
2. Low energy consumption
3. Every cell owns three functions: Air absorption, slurry absorption, and floatation separation, and the cells form a floatation separation loop by itself without any auxiliary equipment, and is allocated horizontally, which favors the change of flow.
4. The circulation of mineral slurry is reasonable, and can avoid the disposition of coarse sand to the largest extent.
5. There is self-control device on the surface of mineral slurry, so it is easy to adjust it.
6. The impeller has backward inclined upper and lower vanes, which produce upper and lower circulation of mineral slurry respectively.
Company Name: Henan Zhengzhou Mining Machinery Co., Ltd.
Official Website: http://www.inczk.com/ & http://www.zkcomp.com/
24-hour Free Sales Consulting Phone: 861-0371 -5590 2866.
Company Address: Qiaolou caizhai industrial estate, Xingyang city, Henan Province
Please pay attention to the company's other products:
Price of rotary kiln: http://www.zkcomp.com/calcining/558. Html
Rotary Kiln: http://www.inczk.com/Products/459. Html
Preheater: http://www.zkcomp.com/calcining/605. Html
Cement Mill: http://www.inczk.com/Products/460. Html
Rotary Dryer: http://www.zkcomp.com/calcining/564. Html
Raw Mill: http://www.inczk.com/Products/1373. Html
Ball Mill: http://www.zkcomp.com/grinding/582. Html
| Model | Volume
(m3) | Cell size
(mm) | Impeller
Dia.(mm) | Capacity
(m3/min) | Power
(kw) |
| BF-0.37 | 0.37 | 740x740x750 | 286 | 0.2-0.4 | 1.5/1.1 |
| -0.65 | 0.65 | 850x950x900 | 300 | 0.3-0.7 | 3/1.1 |
| BF-1.2 | 1.2 | 1050x1150x1100 | 450 | 0.6-1.2 | 5.5/1.1 |
| BF-2.0 | 2 | 1400x1450x1120 | 500 | 1-2 | 7.5/1.1 |
| BF-2.8 | 2.8 | 1650x1650x1150 | 550 | 1.4-3 | 11/1.5 |
| BF-4 | 4 | 1900x2000x1200 | 650 | 2-4 | 15/1.5 |
| BF-6 | 6 | 2200x2350x1300 | 700 | 3-6 | 18.5/1.5 |
| BF-8 | 8 | 2250x2850x1400 | 760 | 4-8 | 30/1.5 |
| BF-10 | 10 | 2250x2850x1700 | 760 | 5-10 | 30/1.5 |
| BF-16 | 16 | 2850x3800x1700 | 850 | 8-16 | 37/1.5 |
| BF-20 | 20 | 2850x3800x2000 | 850 | 10-20 | 37/1.5 |
| BF-24 | 24 | 3150x4150x2000 | 920 | 12-24 | 45/1.5 |
