Product Specifications
| Prod Model: |
SWM615 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Bucket Capacity: |
0.7m3 |
| Rated Load: |
1200kg |
| Min Turning Radius (Mm): |
4500 |
| Dumping Height (Mm): |
2600 |
| Rated Power: |
36.8kw |
| Wheel Base (Mm): |
2005 |
| Overall Dimension (L*W*H): |
4800*1770*2720mm |
| Drive Means: |
4WD |
| Rated Speed Of Engine (Rpm): |
2400 |
| Machine Weight (Kg): |
3600 |
| Walking Mode: |
Wheeled |
| Condition: |
New |
| Type: |
Small Loader |
| Certification: |
ISO9001: 2000 |
| Load And Unload Method: |
Front Discharge |
Product Description
Features
1. The SWM615 wheel loader uses a high-reliability torque converter, gearbox, drive axle and brake system.
2. Using a high-reliability engine, the wheel loader can save more oil, lower noise and emission.
3. Using the hard structural parts and powerful working device, the wheel loader can strengthen the excavating force.
4. The wheel loader is equipped with an advanced hydraulic system and has a full rearview mirror.
5. It has the advantages of large space, low noise, easy operation and so on.
6. Adjusting the swinging angle of the high and rear axle, the wheel loader can smooth its operation in narrow spaces or on rugged sites.
7. The wheel loader has the functions of dustproof, sound insulation, vibration reduction, UV protection and heat insulation.
8. It is equipped with a high-quality seat, made of professional manufacturing technology and characterized by damping suspension.
9. The wheel loader features rigid structure.
|
Main Technical Parameter of SWM615 |
|
Item |
Parameter |
|
Rated load (kg) |
1200 |
|
Bucket capacity (m 3 ) |
0.7 |
|
Wheel tread (mm) |
1480 |
|
Wheel base (mm) |
2005 |
|
Min turning radius (mm) |
4500 |
|
Min ground clearance (mm) |
260 |
|
Dumping height (mm) |
2600 |
|
Corresponding dumping reach (mm) |
1070 |
|
Lifting time (s) |
4 |
|
Hydraulic cycle time (s) |
8.5 |
|
Maximum excavating force (KN) |
36 |
|
Drive mode |
Four are Drive |
|
Machine weight (kg) |
3600 |
|
Overall dimensions (mm) (Length*width*height) |
4800*1770*2720 |
|
Engine model |
A498BT1 |
|
Rated power of engine (kw) |
36.8 |
|
Rated speed of engine (rpm) |
2400 |
Since 1990, Kudat Industry and Trade Company has exported engineering machinery, construction machinery and agricultural machinery to international markets. Satisfying customers' stated and implied needs have always been the focus of business policy of Kudat. As a further step to satisfy customers and to give them confidence in our quality & production capabilities, Kudat has adopted ISO 9001: 2000, the international quality management system. And some of our products have also passed CE and EPA certification.
With a rich inventory of numerous products and vast sourcing capabilities (more than 60 famous manufacturers) cater to the requirements of its customers. Except abundant of products, we also set up factory for studying and producing relative machinery products. From base to top, Kudat holds a unique position in the global market of machinery products which is combination of production and trade.
With 16 years experience in the export of machinery products, Kudat has gained reputation and confidence as a reliable Chinese supplier. By virtue of committed management and dedicated employees, Kudat has gained recognition from the government of China as an excellent exporter.
