Mini Laser Light Diode Module (MN635-05FA) 4*9mm
Product Specifications
| Prod Model: |
MN635-05FA |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Wavelength: |
650nm |
| Lifetime: |
>10, 000hrs |
| Laser Sight: |
Red |
| Port: |
According to Customer Requirements |
| Delivery Time: |
10-20day Depending on The Qty |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Material: |
Laser Diode |
Product Description
1, mini size
2, Industrial quality
3, high reliability
4, low consumption
Mini Laser Light Module
Key Features:
Small Size
Lower Power Consumption
Small Beam Divergence
High Feasibility
Applications:
Surveying Equipments
Laser Alignment and Positioning
Laser Aiming
Machine Vision
Model |
MN635-05FA |
Wavelength |
650nm |
Output power |
1-3mW |
Aperture |
2mm(customized) |
Divergence |
0.8mrad(customized) |
Beam Size |
5*10mm@5M) customized |
Dimension |
4*8mm |
Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.
Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.
Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.
Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
