Product Specifications
| Prod Model: |
D25 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Red |
| Quick Hitch: |
Joystick |
| Transmission: |
Hydrostatic System |
| Walking Mode: |
Wheeled |
| Condition: |
New |
| Type: |
Small Loader |
| Certification: |
CE |
| Load And Unload Method: |
Front Discharge |
Product Description
EURO stage III standard;
Rated power: 18.5kw(24.8bhp);
Rated bucket Load: 0.4CBM;
Four wheel drive;
Dump clearence: 2.20m;
Electric piston pump;
Closed hydrostatic transmission system;
With ROPS & canopy,
With quick hitch and standard Bucket
With all kinds of attachments
Excellent performance
Power features low energy consumption and environmental protection.
The closed hydrostatic system has the feature of lower energy consumption.
Simple quick-change construction can meet multipurpose operation of users.
The integrated multi-functional control handle makes operation simple.
The monitor has the LED showing of fuel level by stages.
The unique frame hinge type is compacted and durable.
The widely applied broad-face tire and damping seat is safe and comfortable.
Small working radius, mobile and flexible.
Engine |
|
Model |
403D-11 |
Rated power |
18.5kw(24.8BHP) |
Rated speed |
2800rpm |
Maximum torque |
67Nm |
|
The ratio of fuel consumption |
252g/kwhr |
Dimensions |
|
Body length |
3690mm |
Body width(reverse tire) |
1050mm/970mm |
Body height |
2300mm |
Minimum ground clearance |
200mm |
Maximum dumping height |
2000mm |
Dumping reach |
600mm |
Wheel base |
1340mm |
Performance parameters of the machine |
Bucket |
0.4m 3 |
|
Tipping load in shovel, vehicle straight |
798kg |
Tipping load in shovel, vehicle at 68° |
498kg |
Operating weight |
1470kg |
The sum of the work device |
8s |
Driving speed |
0-12km/h |
Minimum turning-circle radius |
|
Outside face of bucket |
1989mm |
Outside face of tyre |
1469mm |
Tyre specifications |
27*8.5-15TL |
Maximum turning angle |
±68 degree |
Weifang Map Power Co., Ltd., was founded in 2006. We are a professional manufacture and chain supplier specializing in construction machinery and agricultural equipments. 70% of our products are made for export.
We keep diverse products according to customer and market demand. We produce and supply site dumpers, wheel loaders, tractors, implements, wheel excavators, crawler excavators, backhoe loaders, forklifts, road rollers, light towers, concrete mixers, plate compactor, impact tampers, road cutters, concrete vibrators, and so on.
With experiences in professional manufacturing, Map Power has successfully sold equipments to around 30 countries and areas around the world including Australia, New Zealand, Canada, England, Poland, Dutch, Italy, Russia, India, Main countries of Africa...
Our main products list.
Agricultural machinery:
1. Tractor from 18HO-130HP
2. Farm implemants covered dics mower, lawn mower, tractor mouting front end loader, backhoe loader, sweeping machine, snow blower, dics plow, dics harrow and etc.
Construction machine:
Wheel Loader, Truct Crane, Wheel Excavator, Crawler excavator, Backhoe Loader, Forklift, Road Roller, Concrete Mixer, Plate Compactor, Impact Tampers, Road Cutters, Concrete Vibrators, and so on.
Customer's requirement is our first priority. We can provide reliable, fast and professional service for you through telephone, on-site or network channels. We are ready to provide all customers with 10 years spare parts supply. Furthermore, if your products parts are damaged, please also contact us to see if it could be restored, and if so, you can avoid the trouble and cost of purchasing new spare parts. In our spare parts department, customers can get professional technical advice, as well as the relevant information regarding all products and services
With experiences in professional manufacturing for more than 10 years. WEIFANG MAP POWER Co. Has successfully sold equipments to around 40 countries and areas. We sincerely welcome customers and friends all over the world to visit our factory and cooperate with us in the future.
