Supplier: | Glorytek Industry (Beijing) Co., Ltd. |
---|---|
Price: | US $ 100/Piece |
Min Order: | 1/Piece |
Quantity:: | |
Trade Terms: | FOB,CFR,CIF |
![]() |
Prod Model: | L360-8M |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Item: | L360-8m Tractor Mounted Auger Drill Rig |
Drilling Diameter: | 100-800mm |
Drilling Depth: | 8-15m |
Drilling Speed: | 40-65r/Min. |
Rotary Angle: | 360 Degree |
Oil Pump Pressure: | 16-20MPa |
Gradeability: | 25 Degree |
Travelling Speed: | 40km/H |
Travelling Type: | Diesel Engine or Power |
Min. Ground Clearance: | 230mm |
Type: | Drill |
Our products are widely used in the scope of mining, water well drilling and exploration, anchor grouting project, side slope protection engineering, oil and gas engineering,underwater rock drilling & blasting operations of seaport channel, hydropower project, national defense projects ect.
Main Parameters of drill rig | |
Drilling Diameter | 100-800mm |
Drilling Depth | 8-15M |
Drilling Speed | 40-65r/min. |
Rotary angle | 360 Degree |
Oil Pump Pressure | 16-20mpa |
Oil Pump Flow | 32L/Min. |
Diesel Engine | 36KW/2200r/min |
Generator Unit | 40-50KW |
Gradeability | 25 Degree |
Travelling Speed | 40km/h |
Travelling Type | Diesel engine or power |
Power source | External power supply or Generator operation |
Min. Ground Clearance | 230mm |
Axile Base | 2550mm |
Wheel Base | Front 1860, Rear 1920mm |
Transportation dimensions | 9500*2100*3050mm |
Weight | 7300kg |
