Mpt-II 58mm Bluetooth 2inch RS-232 Portable Thermal Printer
Product Specifications
| Prod Model: |
MPT-II |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
92.5 X 75 X38mm |
| Weight: |
180g |
| Printing Method: |
Thermal Line |
| Printing Speed: |
50~80mm/S |
| Resolution: |
8 Dots/Mm, 384 Dots/Line |
| Emulation: |
ESC/POS |
| Sensor: |
Paper End Sensor, Power Near End Sensor, Cover Ope |
| Interface: |
RS-232 |
| Power Adaptor: |
DC12V/500mA |
| Dimension (Wxlxh): |
92.5 X 75 X38mm |
| Certification: |
CE |
| Type: |
58mm Bluetooth 2inch Thermal Printer |
Product Description
Portable Thermal Printer--Mpt-II
Feature:
-Light weight for true mobility
-Direct thermal printing method
-Easy to use and simple to maintain
-Easy drop-in clamshell paper loading
-Support RS232, IrDA, and Bluetooth interface
-Continuing printing when battery in charging
| Printing Method | Thermal Line |
| Printing Speed | 50~80mm/s |
| Effective Printing Width | 48mm |
| Resolution | 8 dots/mm, 384 dots/line |
| Print Font | ANK: 8x16, 12 x24 GBK: 16x16, 24 x 24 |
| Character per Line | 32 |
| Paper Type | Thermal paper |
| Paper Width | 58mm |
| Paper Roll Diameter | Max: 30.0mm |
| Roll Core Inner Diameter | 13mm(min. ) |
| Paper Thickness | 0.06 to 0.07mm |
| Paper Loading Method | Drop-in easy loading |
| TPH Reliability | 50km |
| Barcode | 1D: UPC-A, UPC-E, EAN-13, EAN-8, CODE39, ITF25, CODABAR, CODE93, CODE128
2D: PDF417, QR code, DATA Matrix |
| Emulation | ESC/POS |
| Sensor | Paper end sensor, Power near end sensor, Cover open sensor |
| Interface | RS-232 |
| Power Adaptor | DC12V/500mA |
| Weight | 180g |
| Dimension (WxLxH) | 92.5 x 75 x38mm |
| Color | Dark Gray |
| Operating Temp | -10~50° C |
| Storage Temp | -20~70° C |
| Operating Humidity | 20~85% |
Shenzhen HCC Technology Co., Ltd, established in 2008 year, is a professional manufacturer engaged in the research, development, production, sale and service of Intelligent Commercial Equipment, such as:
Multi-payment product line -- Handheld POS terminal, Retail POS, mPOS etc.
Automatic Fare Collection (AFC) product line -- Bus validator machine and system etc.
E-commerce Logistics and IOT industry product line -- Handheld PDA, Mobile printer, Barcode scanner / printer, RFID device etc.
Our factory had obtained ISO9001 certificates over 15 year, and production department is over 3, 000 SQM. We are also professional in OEM and ODM service, welcome to customize and develop the smart device to meet customers' indeed application.
Most of our products have passed CE/FCC/RoHS international standard, and also approved by Unionpay, EMV, PCI, Visa, MasterCard Industry Professional Certifications, which greatly ensure the highest level safety and quality of our products.
In the past 11 years, we have deepened in printing and payment industry and expanded markets in Southeast and Central Asia, Middle East Asia, South America, Africa and Europe etc. Our products obtain sustained growing market share, and exported to clients over 100 foreign countries and regions.
Our company's slogan is "Professional Solution Provider for Intelligent Commercial Equipment --- Smart and Reliable".
Shenzhen HCC sincerely wish to cooperate with your esteemed company, and provide most suitable products and solution to your customers. We co-create one more Intelligent and glamorous business world.
