Product Specifications
| Prod Model: |
37TECHMTK750 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Hardware specifications
Configuration
MT7620A+MT7610E
FLASH: SPI 16 MB
RAM: DDR2 128MB (max 256MB)
Protocol standard
IEEE 802.11n,IEEE 802.11g,IEEE 802.11b;IEEE802.11ac
IEEE 802.3,IEEE 802.3u
Wireless rate
750 Mbps
Normal transmission power
802.11g
802.11n
802.11ac
27dBm -+2dBm;
27dBm -+2dBm;
12dBm -+ 2dBm;
Zoom in transmission power
500%=500mw
Receiving sensitivity
802.11b: -83dBm AT 10% PER
802.11g: -70dBm AT 10% PER
802.11g: -70dBm AT 10% PER
802.11n: -63dBm AT 10% PER
802.11ac: -58dBm AT 10% PER
Interface
10/100M , one adaptive WAN, support automatic flip (Auto MDI/MDIX);
10/100M , Four adaptive LAN, support automatic flip (Auto MDI/MDIX);
1 DC interface,
1 USB2.0 interface,
1 MICRO SD
Support 2.4GHz,5.8GHz
Button
Reset button,WPS button
LED
Power,WPS,2.4G,5G,WAN,LAN1,LAN2,LAN3,LAN4
The power supply
12V 1A
Size
217*135*31.7MM
Wireless parameters
The basic function
SSID broadcasting switch
Channel choice: 1-13
Optional: spectrum bandwidth 20 MHZ, 40 MHZ, automatic
Working mode
AP mode
WDS wireless bridge mode
Client
Client AP relay mode
Wireless security
the wireless MAC address filtering
64/128/152 - bit WEP encryption
WPA-PSK/WPA2-PSK WPA/WPA2 security mechanism
Function
Network Settings
WAN connection type automatic detection
WAN connection type support: PPPoE, dynamic IP, static IP
Dial-up way type: automatic dialling, manual dialLing
Support the PPTP, L2TP, OpenVPN (optional)
DDNS dynamic domain name
static routing
DHCP Settings
DHCP server
DHCP client
client list
static address allocation
Port forwarding
a virtual server
special application
DMZ host
UPnP Settings
Security Settings IP and MAC address binding prevention of ARP attacking
IP address filtering
MAC address filtering
DE DoS attack prevention
FLOOD attack prevention
Ping packet control
System tools traffic statistics
system security log
remote Web management
Configuration files, import and export
TFTP software upgrade
Using environment Working temperature: 0 degree to 40 degree
Storage temperature: - 20 degree to 60 degree
Working humidity: 10% to 90% RH without condensation
Store humidity: 5% to 90% RH without condensation
