Product Specifications
| Prod Model: |
PLS-250 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model Number: |
Pls-250+ Motor |
| Dimension(L*W*H): |
1200*420*1000(mm) |
| Warranty: |
12 Months |
| Weight: |
170kg |
| Power: |
11kw |
| Capacity: |
400-500kg/H |
| Specifications: |
2.5mm-6mm |
| Place Of Origin: |
China |
| Certification: |
CE |
| After-Sales Service Provided: |
Engineers Available to Service Machinery Overseas |
| Processing Technics: |
Mixing-before-Crushing |
| Type: |
Pellet Machine |
| Processing Object: |
Crude Fiber |
Product Description
The characteristics of the model:
1. The pressure wheel, and ends with mould disc, outer ring line speed is consistent, do not appear dislocation of the wheel and mould friction, reduce the resistance and reduce the kinetic energy loss, prolong the service life of the mold, reduces the production cost.
2, stable running, uniform set and increased the suppressing area, improve the production efficiency.
3. The structure of pressure regulating screw center, mold clearance over big with small, is suitable for various materials, ensure the suppression effect.
4. The aircraft equipped with Φ multiple aperture mould 4 - Φ 20 mm, to adapt to the different material granulation, achieve the best benefit.
Scope of application:
Is mainly suitable for coarse fiber granulation, such as: sawdust, rice husk, cotton stalk, cotton seed hull, weeds and other crops straw and factory waste, lower bonding rate, difficult to molding material granulation, also can be applied to bio-bacterial manure, organic fertilizer and compound fertilizer granulation in low temperature.Dry into dry out, no need drying (raw material moisture content not less than 10% water standard country exports).
1. Using differential with motor or diesel engine.Low energy, high output, easy to operate.
2, adopt new technology of extrusion granulation, polishing integer, thoroughly solved the traditional granulation process organic material content is low (30%), the difficulty of granulation, such as raw material should be dry crushing processing key technology problem. SKJ - 200, with three extrusion, pressing area increase pressure wheel, reduce friction, reduce energy consumption, low energy, high output.
3, it can produce spherical pure organic fertilizer, organic and inorganic fertilizer, biological organic fertilizer;Uniform particles, smooth, rounded, high strength, good liquidity.
4, the triad of adopting unique techniques used to complete the whole process of low temperature drying, cooling, screening, less equipment investment, low operating cost.Microbial survival rate > 90%.
5, widely used in animal husbandry and aquaculture, medium farms, feed mills, and brewing, sugar, paper making, medicine, cigarette factory, and other industries of organic waste granulation, again is preferred (biological) organic fertilizer production enterprise ideal equipment.
Pellet feed machine
This product USES the template and press roller is made of high quality alloy steel after special treatment, spindle and die under the effect of friction, the drive roller rotation, pressure roller and the template to produce high temperature make the starch aging, clotting protein denaturation, under the roller extruding from the eduction in die hole, particles are sent out with the left closed, cutter Angle can be controlled by adjusting grain length, this machine also implements no v-belts, machine and motor directly connected to avoid the effect of the belt creep crash!NongYou pellet machine is mainly suitable for medium and small-scale farming, such as processing professional production all kinds of livestock and poultry and aquatic granule feedstuff, may reduce the production cost.Can be used for the rabbit, chicken, duck, goose, fish, pig, aquatic products, etc.
Main characteristics:
1, simple structure, wide applicability, cover an area of an area small, low noise.
2, powder feed, grass meal needs no (or little) liquid can be added to granulating.So basic as the moisture content of grain feed granulating before the moisture content of materials, more conducive to storage.
3, the machine is made of particle high hardness, smooth surface, internal curing degree is more fully, can improve the digestion and absorption of nutrition, and can kill pathogenic microorganism and parasite, is suitable for feeding rabbit, fish, duck and experimental animals, higher economic benefit than mixed powder feed can be obtained.
4, the aircraft equipped with 1.5 - more than 20 aperture mould, to adapt to the different material granulation, achieve the best effect.
5, adapt to different materials, guarantee the suppression effect.Sawdust, corn straw takes a lot of pressure, such as compression molding in similar granulating equipment, roller parts is the center of the whole equipment parts, and adopts high quality alloy steel, improve the service life of the roller.
Particles machine right using method
In terms of the new machine:
1, 10-20 jins already mixed powder feed, 5% 10% of cooking oil to make, with the hand rub oil block, to join the first feed, start the machine after using a wrench, adjust the roller bolt to be normal discharge.Feed with oil inside the machine again and again after 3 to 5 times, in gradually add dry ingredients (feed extrusion with oil cannot be used to feed the rabbit. The new machine after running-in again, don't need to be running in again).
2, the regulation of the length of the feed.By adjusting the cutter in discharging mouth, adjust the length of the particles.
3, processing of grain is relatively high temperature should be placed in a well-ventilated place, cool to room temperature storage sack.
Matters needing attention
1, use the new machine for the first time, it is necessary to adjust, otherwise can't normal use.
2, granule machine lighting electricity power supply, power supply cord with not less than 4.5 square meters of copper wire, wire should not be more than 30 meters long.
3, granule machine is working, don't use hand in feeding mouth, if necessary, can use a stick to help feed.
4, the machine open before, you must first add less, to boot.Shut down the machine to be kept inside a few feed, prevent the machine from the roller contact with template idling.
5, machine work, such as appear jam phenomenon, should immediately stop, press roller compaction to bolt after pine flat, then restart the machine.
6, every time after work, will have to adjust the pressure roller bolt loosening.
7, machine using a certain amount of time after a certain number of particles or pressure, if build the grain to pieces or particle false, should put on the mill turn to below 2% - 4% of the water in the mixed feed.
8, check the belt elasticity, prevent the machine production is low, belt creep, etc.
9, particle machines in use for the first time to work 40 hours, low load and changing the gear oil in the gearbox.After 100 hours to change regularly, all bearing grease should be lubricated regularly refill.
10, granule machine continuous work, the motor heat to 70 degrees, is normal phenomenon.
After processed into granule feedstuff has many advantages:
(1) production process in mechanical pressure itself, can make the starch in the feed to a certain degree of maturation, produces a thick fragrance, and feed hard, conform to the meshes on the biological characteristics of pigs, cattle, sheep, improved the feed delicious, easy to eat.
(2) particles in the forming process can make the grains, legumes trypsin less waste.Degeneration does resistance factor function, reduce the adverse effects on the digestive, can kill all kinds of parasitic ovum and other pathogenic microorganisms, reduce all kinds of parasitic diseases and diseases of the digestive system.
(3) feeding convenience, high efficiency, easy to control the feeding amount, save feed, clean health.Especially the fish, as a result of granule feedstuff dissolved in water is slow, not inundated by sediment, can reduce the waste of feed to a great extent.
The product model learned the essence of the pellet machine at home and abroad, for energy saving of new products.After the past general feed processing into powder feeding, feeding is not convenient, poor palatability, livestock picky, low utilization rate of defects.As feed machinery and popularization, the advent of new small particles can now easily powder feed processing into pellet feed.
(4) template and roller adopt high-frequency manganese steel alloy material, has a long service life, reasonable structure, strong hardships and stand hard work.
| Condition: | New | Place of Origin: | China | Brand Name: | Eternal Win |
| Model Number: | PLS-250 | Type: | pellet making machine | Power(W): | 8HPdiesel engine |
| Dimension(L*W*H): | 120*40*100cm | Weight: | 170 kg | Certification: | CE,SGS, GOST, ISO9001, CE,SGS, GOST, ISO9001 |
| Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas | Raw Material: | grain, sawdust, straw |
| Power: | 11Kw | Animal Feed Capacity: | 400-500kg/h | Diameter of Granule: | 2.5/3/6mm |
| Applicable Animal: | aquatic product, poultry, pets, ornamental fish |
|
| Color: | as customer required |
| Main Spare Parts: | engine,gearbox,shaft,roller,die |
|
|
|
|
