Multi-Layers Flexible Printed Circuit Board

Name: Multi-Layers Flexible Printed Circuit Board
Brand: China-Manufacturer-Directory.com
SKU: 700755685
Availability: InStock
Rating: 4.4 (98 reviews)

Supplier:	Fz-Pcb Technology Co., Limited
Price:	Negotiable
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

1, PCB manufacturer
2, ShengYi FR4 material
3, immersion gold
4, green solder mask
5, white silk
6, Board thinkness 1.6mm

Enterprise
1, shorten new products R&D cycle, quick respond and win the marketing.
2, Reduce, Avoid the venture cost for bad quality and delayed
3, Get our professional technics service and PCB training free.

Purchase
1, Never worried about your PCB quality and delivery problem and get your colleague and lead complaint
2, No need to waste time and energy to find a good supplier
3, Personal performance will not influenced by PCB dilivery and quality problems any more
4, Report you boards status after you placing orders, everthing is under your control
5, Improve your working efficiency, get easy and simpleness work

R&D
1, Provide PCB technics support, help you finished PCB final design...
2, Offer you professional suggestion cut down cost from design and shortern R&D circle.
3, Add my skype and MSN get quick response! ! ! !

Item	Mass processing capability	Small batch processing capability
Layer (Max. )	2-12	24-28
Type of the board material	FR-4, high-TG, aluminum base, Rogers, etc., F4, BT	PTFE, PPO, PPE,
Type of the board material	Rogers, etc	E-65, ect
Compound pressed board	4 layers 6 layers	6 layers 8 layers(FR-4+Rogers)
Maximum Size	400mm X 700mm	500mm X 1000mm
Outline Size Tolerance	± 0.13mm	± 0.10mm
V-CUT Deepness Tolerance	+/- 0.15 mm (V-CUT): +/- 0.1 mm (CNC V-CUT)
BoardThicknessRange	0.1mm6.0mm	7.08.0mm
Board Thickness Tolerance ( t≥ 0.8mm)	± 8%	± 5%
Board Thickness Tolerance (t< 0.8mm)	± 10%	± 8%
Medium Thickness(Min)	0.065mm(RCC)	0.05mm
Minimum Line Width	0.075mm(3mil)	0.063mm(2.5mil)
Minimum Line Distance	0.075mm(3mil)	0.063mm(2.5mil)
Line Margin	0.2 mm(CNC): 0.30 mm (punch): . 50 mm (V-CUT)
Outer layer copper thickness	9um140um	175um210um
Inner layer copper thickness	9um140um	175um210um
Drill hole size (mechanical hole)	0.25mm6.00mm	0.15mm0.25mm
Finish Hole size (mechanical hole)	0.10mm6.00mm	0.05mm0.1mm
Hole size tolerance (mechanical hole)	+/- 0.076 mm (normal hole) +/- 0.05 mm (fit-press hole) +0.1/-0.05 mm (punch hole)
Hole position deviation (mechanical hole)	+/-0.075mm: (drill hole): +/- 0.10 mm (punch hole)	0.050mm
Laser hole size	0.10mm (1+n+12+n+2)	0.075mm
Aspect Ratio	10: 1 (drill hole size> 0.2mm)	12: 1(drill hole size> 0.25mm)
Solder mask type	sensitive green, yellow, black, MATT, blue, red ink, and peelable blue glue.
Minimum width of solder mask bridge	0.10mm	0.075mm
Minimum size of solder mask separation ring	0.05mm	0.025mm
Soldermask oil plug hole diameter	0.25mm0.60mm	0.6mm-0.70mm
Impedance tolerance	± 10% (impedance> 50ohm) ± 5ohm(impedance< 50ohm)	± 5% (impedance> 50ohm)
Surface processing type	HAL, plating nickel gold(soft gold/flash gold), thick & hard gold, chemical nickel gold, immersion tin, lead-free H. A. S. L, Entek, gold-finger, and selective surface processing.

Shenzhen fz-PCB company was established in 2003, mainly produce single layer to multi-layer PCB and PCBA. Flytop has about 600 staff in its factory located in Shenzhen, China, with a capacity of 20, 000 square meters (around 200, 000 square feet) per month. Our sales revenues have reached more than 24Million last year. Core electronics manufacture service products have been widely used in telecommunication, power supplier, military, consumer electronic and other fields.

Our products have passed the American UL certification and been compliant with the RoHS Directive. Moreover, flytop is registered ISO9001, ISO/TS16949 system and certified ISO140001 environment system. In order to serve customer well, we have successfully implemented the ERP system. In order to be a green manufacturer, we strictly carry out the government's regulation, and have the water recycle system. Flytop manufacturing services are used by customers in the US, Asia, and Europe, etc. We are ready to handle your needs too. We looking forward to the opportunity to work with you.
