Product Specifications
| Prod Model: |
LWY-CH167 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Testimonial: |
"Amazing Experience Working with Longwanyuan" |
| Warranty: |
30-Year Limited Warranty |
| Technical Innovation: |
No Welding Involved |
| Lifespan: |
50 Years |
| Charity Drive: |
Large Amount Social Donation |
| Building Code Adaptability: |
Suited for Local Building Code |
| Material: |
Steel Structure |
| Usage: |
Temporary Offices |
| Certification: |
BV |
| Customized: |
Customized |
Product Description
Specification of prefabricated building system
Structure - elementsStandardOptional
FoundationConcrete: Plate, strip foundation, single foundation, combinations of typesConcrete: Plate, strip foundation, single foundation, combinations of types
FloorsOSB plates, PVC dressingcement board, cheramic for "wet" spaces
Walls - from exteriourzinced and plastificated plate, low corrugation or casettsprecious plasters, facade bricks, cement boards, HPL
Walls - from interiour and internal wallsgypsum boards, paintedcheramic tiles, zinced plasticated plate
Roofzinced plastificated platetile, imitarion of tiles (hip roof)
Ceilinggypsum boards, paintedenriched chipboard, lowered ceiling, various fillings
WindowsPVC with triple glass, U=0, 86aluminium, wood
Exteriour dooraluminium with termical insulation U=0, 86PVC with termical insulation U=0, 86
Inner dooraluminiumwood
Electric installationsaccording EU normson request
Sanitary installationsmasched instalaltions, plastic tubeson request
Dimensions in 3D modulesLenght 3.0, 6.5 and 9.0 m
Width: 2.44 and 3.0 m
Inner height 2.5 m
Exterior height 3.0 mon request
Up to 3.5 m
Up to 3.0 m
Up to 3.5 m
I. ISO standard dimensions of 20 feet STANDARD flat pack containers - optionally 10 up to 30 feet
Lenght = 6.058 mm (optionally 3.048 - 9.100 mm)
Width = 2.438 mm (optionally 3.000 mm)
Exterior height = 2.591 mm (optionally 2.791 mm or 3100 mm)
Inner height = 2.300 mm (optionally 2.500 mm or 2800 mm)
II. Standard container painting
Option: On customer wish in RAL color
Option: Painted on customer wish in RAL color
III. Container floors:
IV. Container floor opening for forklift
Without forklift pockets
Option: With forklift pockets for containers up to 7.335 mm
Holes distance 1.506mm
V. Container roof construction
VI. Container exterior wall and side panels
50 mm poliurethane panel, externally microcorrugated RAL 9002
Internally smooth RAL 9010 (white)
Option: 60 mm mineral wool, bothside plastificated in RAL 9002
Option: 60 mm mineral wool, bothside plastificated in RAL 9002,
Internally enriched chipboard 100 WHITE010 (white)
Option: 80 mm poliurethane panel, bothside plasticated steel plate RAL 9010 (white)
Option: 100 mm poliurethane panel, bothside plasticated steel plate RAL 9010 (white)
Option: 100 mm mineral wool, bothside plasticated steel plate RAL 9010 (white)
Option: 120 mm mineral wool, bothside plasticated steel plate RAL 9010 (white)
VII. Container exterior and inner walls
PVC with polyurethane filling 40 mm, clear opening 79/202 cm
VIII...Container windows and doors
Option: Windows without shutters
Option: Windows with shutters
IX. Container isolation, coefficient of thermal resistance
Floor - U = 0, 37 W / m2k
Roof - U = 0, 39 W /m2k
Wall panels - U = 0, 41 W /m2k
Windows - U = 2, 40 W / m2k
X. Container construction difference
ZINCED metal profyles 3 mm connected with scres
|
Item |
Option |
|
size |
optionally 10 up to 30 feet
lenght = 6.058 mm (optionally 3.048 - 9.100 mm)
width = 2.438 mm (optionally 3.000 mm)
exterior height = 2.591 mm (optionally 2.791 mm or 3100 mm)
inner height = 2.300 mm (optionally 2.500 mm or 2800 mm) |
|
painting |
on customer wish in RAL color |
option: painted on customer wish in RAL color |
|
container floors |
1.5mm VINYL DRESSING;19mm OSB board;PU PANEL 50 mm;RIB |
LAMINATE OR CHERAMIC TILES;PU PANEL 50 mm;RIB |
|
container roof construction |
50+40mm PU PANEL |
ZINCED STEEL PLATE COVER 0.6mm;100mm MINERAL WOOL;STEEL 40*80mm;PVC foil vapour barrier;Enriched white chipboard 10mm |
|
container exterior wall and side panels |
container exterior wall and side panels
50 mm poliurethane panel, externally microcorrugated RAL 9002
internally smooth RAL 9010 (white) |
option: 60 mm mineral wool, bothside plastificated in RAL 9002
option: 60 mm mineral wool, bothside plastificated in RAL 9002, internally enriched chipboard 100 WHITE010 (white)
option: 80 mm poliurethane panel, bothside plasticated steel plate RAL 9010 (white)
option: 100 mm poliurethane panel, bothside plasticated steel plate RAL 9010 (white)
option: 100 mm mineral wool, bothside plasticated steel plate RAL 9010 (white)
option: 120 mm mineral wool, bothside plasticated steel plate RAL 9010 (white) |
|
container exterior and inner walls |
container exterior and inner walls
PVC with polyurethane filling 40 mm, clear opening 79/202 cm |
|
container window and doors |
windows without shutters |
windows with shutters |
|
container isolation,coefficient of thermal resistance |
floor - U = 0,37 W / m2k
roof - U = 0,39 W /m2k
wall panels - U = 0,41 W /m2k
windows - U = 2,40 W / m2k |
container floor opening for forklift |
without forklift pockets |
option: with forklift pockets for containers up to 7.335 mm
holes distance 1.506mm |
