Product Specifications
| Prod Model: |
MLT-19 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: |
Polyester Glass Fiber Mat Laminate |
| Structure: |
Combining Rigid Circuit Board |
| Production Process: |
Electrolytic Foil |
| Brand: |
Mlt Circuits |
Product Description
Additional Info.
Packing:Inner; Vacuum Packing; Dry Packing out Packing
Origin:Shenzhen, Guangdong
Product Description
PCB Manufacturer in China with High Quality
1. PCB, pcba, pcb design
2. UL, ROHS
3. Fast delivery with quality assured
4. ISO9001 certificate
5. Smt Pick And Place Pcb Assembly
Needed:
1. PCB gerber file.
2. BOM LIST FOR PCB ASSEMBLY.
3. Send us your sample pcb board or PCBA.
One-stop pcb assemblies service, We can offer 1 to 28 Layer PCB fabrication, PCB design, PCB layout, PCB manufacturing, PCB Assemblies, components sourcing, PCBA Function Test, design solution.
Technical capability & support
MLT aims to be the leading PCB manufacturer, and provide quality PCB products for electronic industry.
| Layers | 1-16 layers | Min Board Thickness(2-layer) | 0.2mm |
| Max Board Size | 635 × 1100mm | Min Board Thickness(4-layer) | 0.6mm |
| Min Board Size | 20 × 30mm | Min Inner-layer Thickness | 0.1mm |
| Min Trace | 0.1mm | Min Annular Ring | 0.1mm |
| Min Space | 0.1mm | Min Hole Location Tolerance | ±0.075mm |
| Min Hole Size | 0.2mm | Min Hole Size Tolerance | ±0.05mm |
| Board Wrap | ≤ 1° | Min Outer Dimension Tolerance | ±0.1mm |
| Solder Mask | Green, Yellow, Red, Black, Blue, White |
| Surface Finish | HAL, HASL, Immersion Gold, Immersion Silver, Plating Gold, Plating Nickel, Plating Silver, Gold Finger, OSP |
| Board Material | FR-4, High Tg FR-4, Halogen Free FR-4, Thick Copper FR-4, Aluminium Based, Rogers, Taconic |
| Acceptable file | Gerber file(RS-274-X or RS-274-D with aperture list and drill files),Protel,PADS,POWERPCB,AutoCAD,ORCAD |
| CAM software | Genesis, CAM350 |
Why choose MLT
1. Reliable Quality Control
We are constantly introducing the most advanced equipment, and strive to provide customers with higher quality products. At the same time, our production and quality control strictly comply with ISO and UL standard. At present, we are applying for TS16949, we also welcome your supervision on our quality.
2. Flexible quotation system
that we have two branch factories, one is mainly focus on simple boards or the customers want to a much competitive price. Another is focus on complex boards or special material, also customized boards.
3. Much Competitive Price
We do not only pay attention on products quality and service, but also the much competitive price is our advantage. Our price advantage is especially pronounced on Quick Turn, Medium volume and Large volume. More details, please contact us.
4. Professional Service Support
We are a young but experienced service team, we have high-spirited and fill with passion, and we use professional technology knowledge to provide customers with professional service, to win the trust of the customers and provide them with perfect products. We regard each request of new product or new technology as a challenge of our improvement.
5. Best Terms of Payment
We have been trying to provide the customers with best service, so we wish to have better support on the payment at the same time. Our payment terms are T/T in advance and 30 day term. You can let us know about your usual way of payment, we will try our best to meet your requirements if needed.
6. Diversified service support
We know that would be a hard start for you to work with us, maybe you worry about our credit rating, product quality or delivery time. In order to dispel any of these doubts, we provide the best support as we can at the beginning of our cooperation.
7. Fast QUICK TURN service
We provide Quick Turn service for PCB prototype projects. The lead time is 24 hours for 2~4 layer, 48 hours for 6~8 layer, 72 hours for 10 layer. More details, please see QUICK TURN or contact us.
8. Strong supply ability
Our own factory can meet 90% order requirements of the all customers, for the rest 10% high precision boards, we will outsource to our excellent partners. Such as China Fastprint, Shennan, Suntak, KingBrother, Wuzhu, Multilayer, Sunshine. To be honest, we are clear that we are unable to solve all PCB requirements, but with a good supply chain, also with stable and long-term business relationship with those outstanding PCB enterprises, enable us dare to accept your projects.
9. Perfect After-Sales Service
We have formed a specialized group for after-sales service, for quick response once we get a complaint, our service team will analyze the reason, make improvement, and work out the best solution for compensation after negotiating with our customers.
MEILAITE established in 2009, is a diversified and innovative PCB service provider who is specializing in develop, design, manufacturing and sales of high quality printed circuit board focusing on quick turn, prototype, medium and large volumes.
MEILAITE is one of the competitive suppliers in China to provide high quality and 100% reliable PCBs. We are professional in high-end prototype, Quick Turn, medium to large volume PCB manufacturing.
Our mainly products are single side, double side and multilayer PCBs up to 28 layer and we have excellent experience in Metal based PCBs, High TG boards, High frequency boards, Impedance control boards, heavy copper boards, HDI, Blind and Buried VIAs, Mixed boards, Flex boards, Rigid-Flex boards. The products are widely applied in various fields such as Communications, power electronics, Industrial Control, Computer, Medical, Aeronautics & Astronautics, security systems, Military, Automatic.
All the products are complied with ISO9001 quality assurance system, UL and RoHS in MEILAITE, currently we are applying for TS16949 certificate for Automatic and Military. With the scientific management, high and stable quality, exquisite techniques, professional service and delivery on time, MEILAITE enjoys strong support and highly regarded by the worldwide customers and the other PCB manufacturers.
MEILAITE will continuously strive for the least defects while committing to efficient communication, delivery on time and unparalleled solutions. We are dedicated to providing PCBs on time with the best price as well as help the customer to set up their own advantage, improve the efficiency of research and development, speed up the production, reduce their production cost, this would be beneficial for them to capture more business.
