Product Specifications
| Prod Model: |
3LYG/4LYG |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Layer: |
3 or 4 Layer |
| Deck Type: |
Coars Deck, Find Sand Deck or Slime Deck Optional |
| Testing: |
Supply |
| Analyse: |
Supply |
| Flowchart: |
Supply |
| Installation: |
Supply |
| Spare Parts: |
Supply |
| Delivery Time: |
30 Days |
| Visit Factory: |
Welcome |
| Type: |
Gravity Separator |
| Voltage: |
380V |
| Certification: |
SGS |
| Warranty: |
1 Year |
| Color: |
Black |
| Customized: |
Customized |
| Condition: |
New |
| Material Feature: |
Corrotion Resistant |
Product Description
Shaking Table which is also called table concentrator, it's effective in processing precious and base metal, rare metal and non-metallic minerals, widely used in separation for Gold, Silver, Tin, Columbium, Tantalum, Titanium, Barium, Tungsten, Iron, Chrome, Manganese, Zircon, Lead, Zinc, Mercury, Copper, Aluminum, etc. The range of effective separating particle size of shaking table is 2 to 0.022 mm.
Advantages and Characteristics
Ingenious structure of inertial gearing, self balanced vertical force component. No vertical jump because no vertical vibrating force. It can be installed on the building floor, or on the bracket
Lift type, minimal consumption of friction, reduce vibration and energy-saving, non-required bulky base, quick and flexible installation
It adopts fiberglass deck with wear-resistant layer, wear-resistant, waterproof, anti-dry, anticorrosion, non-deformed, less maintenance, long service life
The deck installed in an uniform frame Layer-by-layer, easy to install and unload, increase processing capacity per unit area. Replace different weight blocks can change the stroke of shaking table
It adopts variable-frequence governor, easily change frequency of stroke to adapt different material with different particle size and feature
Main Technical Parameters
| Model | 3LYG | 4LYG |
| Deck type | Coarse ore Deck | Fine sand
Deck | Slime Deck | Coarse ore Deck | Fine sand
Deck | Slime Deck |
| Beneficiation area (m2) | 7.6 X 3 | 7.6 X 3 | 7.6 X 3 | 7.6 X 4 | 7.6 X 4 | 7.6 X 4 |
| Deck Size | Length
(mm) | 4500 | 4500 | 4500 | 4500 | 4500 | 4500 |
Transmission end width
(mm) | 1850 | 1850 | 1850 | 1850 | 1850 | 1850 |
Concentrate end width
(mm) | 1550 | 1550 | 1550 | 1550 | 1550 | 1550 |
| Maximum feeding size (mm) | 2 | 0.5 | 0.074 | 2 | 0.5 | 0.074 |
| Capacity (t/h) | 4-5 | 2-3 | 1.5-2.5 | 5-6.5 | 3-5 | 2-3.5 |
| Feeding density (%) | 20-30 | 18-25 | 15-20 | 20-30 | 18-25 | 15-20 |
| Stroke (mm) | 8,10,12,15,18,20,22 |
| Frequency of stroke (r/min) | 270-360(variable-frequence) |
| Water consumption (t/h) | 0.7-1 | 0.4-0.7 | 0.4-0.7 | 0.7-1 | 0.4-0.7 | 0.4-0.7 |
| Groove shape of deck | Available Rectangular, Saw-tooth, Triangle |
| Power (Kw) | 1.5Kw | Dimensions (mm) | 6330×2450×2660 |
|
|
|
|
|
|
|
|
|
|
FAQ
Weclome to visiting our factory to check the machines or send to my email as follow information.
1.Capacity of project?
2.Particle size of original ore?
3.What kind of mineral ores ?
4.Kindly let me know the electric power of your country , here we are 380V 50HZ 3PHASE
We will suggest you the best type and good machines for respect customers.
Why choose our company machine?
1. We are factory (NOT Dealer)
All machinery from Well-tech international equipment Mining Machinery Manufactory are made by ourselves, No trade company make
Commission(many trade companies do not produce the machinery),the lower price with the same goods, good quality, after service can be assured (after service of trade companies will get help from factory).
So please buy from factory
2. We will do our best to satisfy every customer's needs
Producing high-quality and reliable machines is our first priority, because we know that our success depends entirely on the satisfaction of our customers. We never give-up quality to save cost.
3. Training & service
Training is FREE to every customer. Whenever you need us, for installation, maintenance, or proper use of our company machines, we will be right there for you. In addition, we provide one-year warrantee to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.
4. If you are new for this business, I will help you
Many thanks for your trust; we can provide you with the pre-services of design scheme for complete production lines, spot inspection and operator training according to your demands and the conditions of applied spot, we can help you choose the right equipments, drilling rig, Loader, trucks, excavators and so on
5. We will recommend a suitable type for you and send you a best quotation
Our Services
1) Pre-sale service: Freely provide project designing, process designing, choosing suitable equipment for you.
2) Medium-sales service: Accompany you to complete the acceptance of the equipment, draft the construction scheme and detailed process, and complete process of export
3) After-sales service: We sent engineer to the scene to guide installation, debugging and training operators.
